Sony CDP-X3000 - Waveform Analysis; Servo Section Waveforms

– 37 –
• Waveforms
– SERVO Section –
1 IC107 !§ (RFO) 200 mV/DIV, 500 nsec/DIV
4 IC105 $∞ (LRCK)
3 IC107 !∞ (FE) 200 mV/DIV, 50 nsec/DIV
2 IC107 !£ (TE) 200 mV/DIV, 100 µsec/DIV
5 IC105 $¶ (BCLK)
6 IC105 %∞ (RFCK)
7 IC105 ^™ (XTAI)
8 IC104 1
1.2 Vp-p
+0.25
–0.2
5.4 Vp-p
472 nsec
Approx. 400 mVp-p
5.3 Vp-p
136 µ sec
Approx. 200 mVp-p
2.8 Vp-p
56.4 nsec
5.3 Vp-p
22.8
µ
sec
3.5 Vp-p
176 nsec
