Sony CDP-X559ES - Notes on Handling the Optical Pick-Up Block or Base Unit; Notes on Laser Diode Emission Check; Model Identification

_ CDP-X559ES
TABLE OF CONTENTS
Section Title Page
1. GENERAL
te). Identifying the Parts ccrcccctccect este eeeeccee seer eseeesneeeeesenes 3
2. ELECTRICAL BLOCK CHECKING ----:--ersreereeeeeeeree 5
3. DIAGRAMS
3-1. Block Diagram Tere TTrrrrreererreerreeerrerrer er reer reer eee T eee eet ve
3-2. Circuit Boards Location PYETTTETETITETITITITEETETILIT TET T TTT 10
3-3. Printed Wiring Boards aisha ia. 6's :u'e'se:w'aieis'e bien’ win 6 eine Sele .eieio ween esinie’s ll
3-4. Schematic Diagram <s:::rrrerresstetessseeessseeesseeseeeeesnees 15
3-5, Semiconductor Lead Layouts Sainiey gain e.bbine 1406.8 ONT edie winleeleiste’s, 22
4. EXPLODED VIEWS
4-1. Cabinet Section ibs ae 960-96 MANN See. ON iS 8 or 01,6 6 16 © wimin'aceja'aTe Diaie\e'6, ele own ocace wialalee 23
4-2, Front Panel Section PPTETUETEETIRITESE TELE ITE T EEK TTE TTT TET) 24
4-3, Chassis Section He oigeG ip 90a eee ber aislg. Sieiaccia.cHais'e:.0i ele-e 0s #0Gia8 4 8 bee waa ee en 25
4-4, CD Mechanism Block Section Dev encceccen cnc seeeeceesosencsees 26
4-5, Base Unit Section ‘a. G:4.0l0 2 on. 0°0'eib as-is Sieie, wisi eie\erereisin tia'e's Sik. SiRels)eG-bieie eis: 27
5, ELECTRICAL PARTS LIST aid wield, o siaieieieiwvein oie-6't.e-a/a:t's c'e'e S wieiaielsiere:e's: 28
For the United Kingdom and
European countries
LASER product.
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE | The CLASS 1LASER
| PRODUCT label is located
on the rear exterior.
This Compact Disc player
is classified as a CLASS 1
NOTES ON HANDLING THE OPTICAL PICK-UP
BLOCK OR BASE UNIT
The laser diode in the optical pick-up block may suffer
electrostatic breakdown because of the potential di-
ference generated by the charged electrostatic load,
etc. on clothing and the human body.
During repair, pay attention to electrostatic break-
down and also use the procedure in the printed matter
which is included in the repair parts.
The flexible board is easily damaged and should be
handled with care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to
be focused on the disc reflective surface by the objec-
tive lens in the optical pick-up block. Therefore, when
checking the laser diode emission, observe from more
than 30cm away from the objective lens.
MODEL IDENTIFICATION
—Model Number Label—
SONY: move no. cpp-x559Es
COMPACT DISC PLAYER
WMV bbb
AEP model: AC: 220—230V~50/60Hz
UK model: AC: 240V~50/60Hz
E model: AC: 110, 120, 220, 240V~50/60Hz 29W
SAFETY-RELATED COMPONENT WARNINGI!
COMPONENTS IDENTIFIED BY MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DI AGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
