Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
63
* CN105 1-580-772-11 PIN, CONNECTOR (PC BOARD) 4P
CN201 1-580-774-11 PIN, CONNECTOR (PC BOARD) 6P
CN202 1-580-775-11 PIN, CONNECTOR (PC BOARD) 8P
CN203 1-580-770-11 PIN, CONNECTOR (PC BOARD) 2P
CN251 1-580-774-11 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D131 8-719-210-33 DIODE EC10DS2TE12R
D132 8-719-210-33 DIODE EC10DS2TE12R
D201 8-719-914-44 DIODE DAP202K-T-146
D202 8-719-938-07 LED GL480 (STABILIZER DETECT)
D203 8-719-976-96 DIODE DTZ-TT11-4.7C
D204 8-719-210-21 DIODE 11EQS04-TA2B
< IC >
IC101 8-752-369-78 IC CXD2545Q
IC102 8-759-071-79 IC BA6297AFP-T1
IC103 8-759-100-96 IC NJM4558M-T1
IC104 8-759-071-79 IC BA6297AFP-T1
IC105 8-759-071-79 IC BA6297AFP-T1
IC106 8-759-980-44 IC TL712CPS-E05
IC107 8-759-711-85 IC NJM4580E-D (T1)
IC108 8-759-100-96 IC NJM4558M-T1
IC109 8-759-242-70 IC TC7WU04F-TE12L
IC110 8-759-100-96 IC NJM4558M-T1
IC111 8-759-100-96 IC NJM4558M-T1
IC201 8-752-909-65 IC CXP84124-085Q
IC202 8-759-336-84 IC LC3564SM-10-TRM
IC203 8-749-010-61 IC IS471F
IC204 8-759-636-16 IC M51957AL
IC205 8-759-822-09 IC LB1641
< SHORT >
JW104 1-216-295-00 SHORT 0
JW105 1-216-295-00 SHORT 0
< COIL >
L101 1-424-122-11 FILTER, NOISE
L102 1-424-122-11 FILTER, NOISE
L103 1-414-510-21 INDUCTOR 3.3uH
L104 1-414-510-21 INDUCTOR 3.3uH
< TRANSISTOR >
Q101 8-729-232-69 FET 2SK208-GRT5LSONY-1
Q102 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q103 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q104 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q105 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q106 8-729-900-53 TRANSISTOR DTC114EKA-T146
Q151 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q152 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q153 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q154 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q171 8-729-232-69 FET 2SK208-GRT5LSONY-1
Q172 8-729-232-69 FET 2SK208-GRT5LSONY-1
Q181 8-729-232-69 FET 2SK208-GRT5LSONY-1
Q182 8-729-232-69 FET 2SK208-GRT5LSONY-1
Q190 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q201 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q202 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R101 1-216-077-00 RES, CHIP 15K 5% 1/10W
R102 1-216-097-00 RES, CHIP 100K 5% 1/10W
R103 1-216-077-00 RES, CHIP 15K 5% 1/10W
R104 1-216-037-00 METAL CHIP 330 5% 1/10W
R105 1-216-077-00 RES, CHIP 15K 5% 1/10W
R106 1-216-042-00 METAL CHIP 510 5% 1/10W
R107 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R108 1-216-121-00 RES, CHIP 1M 5% 1/10W
R109 1-216-081-00 METAL CHIP 22K 5% 1/10W
R110 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R111 1-216-073-00 METAL CHIP 10K 5% 1/10W
R112 1-216-121-00 RES, CHIP 1M 5% 1/10W
R113 1-216-073-00 METAL CHIP 10K 5% 1/10W
R114 1-216-073-00 METAL CHIP 10K 5% 1/10W
R115 1-216-035-00 METAL CHIP 270 5% 1/10W
R116 1-216-035-00 METAL CHIP 270 5% 1/10W
R117 1-216-073-00 METAL CHIP 10K 5% 1/10W
R118 1-216-081-00 METAL CHIP 22K 5% 1/10W
R119 1-216-081-00 METAL CHIP 22K 5% 1/10W
R120 1-216-101-00 METAL CHIP 150K 5% 1/10W
R121 1-216-081-00 METAL CHIP 22K 5% 1/10W
R122 1-216-081-00 METAL CHIP 22K 5% 1/10W
R123 1-216-081-00 METAL CHIP 22K 5% 1/10W
R124 1-216-089-00 RES, CHIP 47K 5% 1/10W
R125 1-216-089-00 RES, CHIP 47K 5% 1/10W
R126 1-216-025-00 METAL CHIP 100 5% 1/10W
R127 1-216-025-00 METAL CHIP 100 5% 1/10W
R128 1-216-025-00 METAL CHIP 100 5% 1/10W
R129 1-216-073-00 METAL CHIP 10K 5% 1/10W
R130 1-216-295-00 SHORT 0
R131 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R132 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R133 1-216-083-00 METAL CHIP 27K 5% 1/10W
R134 1-216-083-00 METAL CHIP 27K 5% 1/10W
R135 1-216-090-00 METAL CHIP 51K 5% 1/10W
R136 1-216-090-00 METAL CHIP 51K 5% 1/10W
R137 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R138 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R139 1-216-083-00 METAL CHIP 27K 5% 1/10W
R140 1-216-083-00 METAL CHIP 27K 5% 1/10W
R141 1-216-085-00 METAL CHIP 33K 5% 1/10W
R142 1-216-085-00 METAL CHIP 33K 5% 1/10W
R143 1-216-093-11 RES, CHIP 68K 5% 1/10W
R144 1-216-093-11 RES, CHIP 68K 5% 1/10W
R145 1-216-085-00 METAL CHIP 33K 5% 1/10W
R146 1-216-085-00 METAL CHIP 33K 5% 1/10W
R147 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R148 1-216-073-00 METAL CHIP 10K 5% 1/10W
R149 1-216-073-00 METAL CHIP 10K 5% 1/10W
R150 1-216-073-00 METAL CHIP 10K 5% 1/10W
R151 1-216-097-00 RES, CHIP 100K 5% 1/10W
R152 1-216-001-00 METAL CHIP 10 5% 1/10W
R153 1-216-001-00 METAL CHIP 10 5% 1/10W
R154 1-216-073-00 METAL CHIP 10K 5% 1/10W
SERVO
