Sony CDP-XA555ES - Electrical Parts List - Servo, SW, VR Resistors; Servo, SW, VR Board Resistors List

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
64
R155 1-216-097-00 RES, CHIP 100K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-085-00 METAL CHIP 33K 5% 1/10W
R161 1-216-075-00 METAL CHIP 12K 5% 1/10W
R162 1-216-091-00 METAL CHIP 56K 5% 1/10W
R163 1-216-093-11 RES, CHIP 68K 5% 1/10W
R164 1-216-093-11 RES, CHIP 68K 5% 1/10W
R165 1-216-093-11 RES, CHIP 68K 5% 1/10W
R166 1-216-097-00 RES, CHIP 100K 5% 1/10W
R167 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R168 1-216-097-00 RES, CHIP 100K 5% 1/10W
R171 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R172 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R173 1-216-113-00 METAL CHIP 470K 5% 1/10W
R174 1-216-113-00 METAL CHIP 470K 5% 1/10W
R175 1-216-105-00 RES, CHIP 220K 5% 1/10W
R176 1-216-105-00 RES, CHIP 220K 5% 1/10W
R177 1-216-121-00 RES, CHIP 1M 5% 1/10W
R178 1-216-121-00 RES, CHIP 1M 5% 1/10W
R179 1-216-001-00 METAL CHIP 10 5% 1/10W
R181 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R182 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R183 1-216-113-00 METAL CHIP 470K 5% 1/10W
R184 1-216-113-00 METAL CHIP 470K 5% 1/10W
R185 1-216-105-00 RES, CHIP 220K 5% 1/10W
R186 1-216-105-00 RES, CHIP 220K 5% 1/10W
R187 1-216-121-00 RES, CHIP 1M 5% 1/10W
R188 1-216-121-00 RES, CHIP 1M 5% 1/10W
R189 1-216-001-00 METAL CHIP 10 5% 1/10W
R190 1-216-073-00 METAL CHIP 10K 5% 1/10W
R191 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R192 1-216-049-11 RES, CHIP 1K 5% 1/10W
R193 1-216-001-00 METAL CHIP 10 5% 1/10W
R194 1-216-113-00 METAL CHIP 470K 5% 1/10W
R195 1-216-113-00 METAL CHIP 470K 5% 1/10W
R196 1-216-085-00 METAL CHIP 33K 5% 1/10W
R197 1-216-033-00 METAL CHIP 220 5% 1/10W
R198 1-216-049-11 RES, CHIP 1K 5% 1/10W
R199 1-216-049-11 RES, CHIP 1K 5% 1/10W
R201 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R202 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R203 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R204 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R205 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R206 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R207 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R208 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R209 1-216-073-00 METAL CHIP 10K 5% 1/10W
R211 1-216-097-00 RES, CHIP 100K 5% 1/10W
R212 1-216-013-00 METAL CHIP 33 5% 1/10W
R213 1-216-073-00 METAL CHIP 10K 5% 1/10W
R214 1-216-073-00 METAL CHIP 10K 5% 1/10W
R215 1-216-021-00 METAL CHIP 68 5% 1/10W
R216 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R217 1-216-077-00 RES, CHIP 15K 5% 1/10W
R218 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R219 1-216-045-00 METAL CHIP 680 5% 1/10W
R220 1-216-073-00 METAL CHIP 10K 5% 1/10W
R221 1-216-073-00 METAL CHIP 10K 5% 1/10W
R222 1-216-097-00 RES, CHIP 100K 5% 1/10W
R223 1-216-073-00 METAL CHIP 10K 5% 1/10W
R224 1-216-073-00 METAL CHIP 10K 5% 1/10W
R230 1-216-295-00 SHORT 0
R231 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R232 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R233 1-216-085-00 METAL CHIP 33K 5% 1/10W
< VIBRATOR >
X201 1-577-082-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
1-674-836-11 SW BOARD
*********
< CONNECTOR >
* CN995 1-696-874-21 LEAD (WITH CONNECTOR)
< SWITCH >
0 S991 1-572-267-51 SWITCH, PUSH (AC POWER) (1 KEY) (!)
**************************************************************
1-674-837-11 VR BOARD
*********
* 4-962-201-01 PLATE (HP), GROUND
< CAPACITOR >
C350 1-136-165-00 FILM 0.1uF 5% 50V
C351 1-136-165-00 FILM 0.1uF 5% 50V
C461 1-162-290-31 CERAMIC 470PF 10% 50V
C561 1-162-290-31 CERAMIC 470PF 10% 50V
< CONNECTOR >
CN351 1-764-345-11 PIN, CONNECTOR (PCB) (L TYPE)8P
* CN352 1-580-772-11 PIN, CONNECTOR (PC BOARD) 4P
CN461 1-764-326-11 PIN, CONNECTOR (PCB) (V TYPE)3P
< IC >
IC350 8-759-962-08 IC BA6208
< JACK >
J461 1-750-162-61 JACK (LARGE TYPE) (PHONES)
(AEP: BLACK, Singapore)
J461 1-779-219-11 JACK (LARGE TYPE) (PHONES) (AEP: GOLD)
< COIL >
L350 1-414-512-21 INDUCTOR 6.8uH
L461 1-414-512-21 INDUCTOR 6.8uH
L561 1-414-512-21 INDUCTOR 6.8uH
< VARIABLE RESISTOR >
RV350 1-223-747-11 RES, VAR, CARBON 10K/10K
(LINE OUT PHONE LEVEL)
************************************************************
SERVO SW VR
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
