Sony CDP-XA555ES - Page 65

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
65
MISCELLANEOUS
**************
0 106 1-558-568-21 CORD, POWER
114 1-500-219-11 BEAD, FERRITE (CASE)
705 1-769-110-11 WIRE (FLAT TYPE) (26 CORE)
* 706 1-654-005-11 FLEX RELAY BOARD
709 1-769-109-11 WIRE (FLAT TYPE) (12 CORE)
0 805 8-820-014-13 OPTICAL PICK-UP KSS-273B/J1N
820 1-653-918-11 PC BOARD, FLEXIBLE
M21 X-4945-920-1 MOTOR ASSY, SLED
M271 X-4945-565-1 MOTOR ASSY
S21 1-571-958-11 SWITCH, PUSH (1 KEY) (LIMIT OUT)
S22 1-571-958-11 SWITCH, PUSH (1 KEY) (LIMIT IN)
0 T901 1-435-067-11 TRANSFORMER, POWER
0 T902 1-435-068-11 TRANSFORMER, POWER
0 T903 1-435-069-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-246-14 SCREW +KTP 3X8 TYPE2 NON-SLIT (GOLD)
#1 7-685-246-19 SCREW +KTP 3X8 TYPE2 NON-SLIT (BLACK)
#2 7-685-886-09 SCREW +BVTT 4X20 (S)
#3 7-682-548-09 SCREW (3X8)
#4 7-621-775-10 SCREW +B 2.6X4
#6 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#7 7-685-871-01 SCREW +BVTT 3X6 (S)
#8 7-685-872-09 SCREW +BVTT 3X8 (S)
#9 7-682-903-01 SCREW +PWH 3X5
#10 7-682-902-11 SCREW +PWH 2.6X5
#11 7-621-775-60 SCREW +B 2.6X12
#12 7-628-253-00 SCREW +PS 2X4
#13 7-621-772-30 SCREW +B 2X6
#14 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#15 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#16 7-685-902-21 SCREW +PTPWH 2.6X8 (TYPE2)
#17 7-627-852-07 SCREW, PRECISION +P 1.7X2.5
#18 7-627-852-58 SCREW, PRECISION +P 1.7X5 TYPE3
#19 7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-418-691-11 REMOTE COMMANDER (RM-D951)
1-791-732-11 CORD, CONNECTION
3-867-064-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
SPANISH)
3-867-064-21 MANUAL, INSTRUCTION (GERMAN, DUTCH,
SWEDISH, ITALIAN, PORTUGUESE) (AEP)
3-867-064-31 MANUAL, INSTRUCTION (CHINESE)
(Singapore)
4-981-643-01 COVER, BATTERY (for RM-D951)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
