– 12 –
2-5. MAIN BOARD
2-6. HEAT SINK
2
PTT 2.6x
8
4
screws (+BTT)
3
screw (+BTT)
1
PTT 2.6x8
5
MAIN board
1
PTT 2.6x
8
2
PTT 2.6x10
3
PTT 2.6x8
4
heat sink
