CDX-GT35UW
11
3-9.
SLED MOTOR
ASSY
3
sled motor assy
sled motor assy
1
spring
spring
stand
stand
turn table
2
three serration screws
(M
2
u
3)
three serration screws
(M 2
u
3)
Note: Place the stand with care not to touch the turn table.
Note:
Never remove these parts since they were adjusted.
bearing (R)
bearing (F)
Note for
Assembly
Note: T
ake care to prevent the chassis from being bent
when tightening the three machine screws.
10
12
