CDX-GT61UMS/GT560UE/GT560UI/GT560US/GT564UI/GT610UG/GT610US/GT616UG
16
3-9. CHASSIS (OP) ASSY
3-10. CHUCKING ARM SUB ASSY
6 two coil springs (damper) (natural)
7 coil spring (damper) (blue)
8 chassis (OP) assy
5
1 tension spring (KF)
2 gear (LE1)
3 lever (D)
4 slider (R)
3 chucking arm sub assy
2
1 spring
Note 1:
Have this portion receive the chassis.
Note 1:
Have this portion receive the chassis.
Note 2:
Be careful not to touch the turn table.
To Next Page
