43
CDX-GT61UMS/GT560UE/GT560UI/GT560US/GT564UI/GT610UG/GT610US/GT616UG
SECTION 6
ELECTRICAL PARTS LIST
KEY BOARD
**********
< CAPACITOR >
C902 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C904 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C905 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C906 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C907 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C908 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C909 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C910 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C911 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C912 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C916 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN901 1-842-265-22 PLUG, CONNECTOR 20P
< DIODE >
D901 6-502-961-01 DIODE DA2J10100L
D902 6-503-202-01 DIODE RKZ5.1B2KGP1
D906 6-503-213-01 DIODE RKZ18B2KGP1
D907 6-503-205-01 DIODE RKZ6.8B2KGP1
D908 6-503-205-01 DIODE RKZ6.8B2KGP1
D909 6-503-205-01 DIODE RKZ6.8B2KGP1
< FERRITE BEAD >
FB901 1-414-385-21 INDUCTOR, FERRITE BEAD
FB902 1-414-385-21 INDUCTOR, FERRITE BEAD
FB903 1-414-385-21 INDUCTOR, FERRITE BEAD
< IC >
IC901 6-717-496-01 IC LC75839PW-US-H
IC902 6-600-629-01 IC RS-470
< LED >
LED901 6-503-227-01 LED NESW505DT
-A0-UV (LCD BACK LIGHT)
LED930 6-502-195-11 LED SML-D12D8WT86TQ (ILLUMINATION)
(GT610UG: AR)
LED931 6-502-193-11 LED SML-D12V8WT86TN (ILLUMINATION)
(GT560US/GT564UI/GT610UG/GT610US/
GT616UG)
LED931 6-502-325-11 LED SML-D12P8WT86TK (ILLUMINATION)
(GT560UE)
LED931 6-502-542-01 LED SCM015BC7TT86P (ILLUMINATION)
(GT560UI)
LED931 6-503-082-01 LED LNJ437W840S0 (ILLUMINATION)
(GT61UMS)
LED932 6-502-195-11 LED SML-D12D8WT86TQ (ILLUMINATION)
(GT610UG: AR)
LED933 6-502-193-11 LED SML-D12V8WT86TN (ILLUMINATION)
(GT560US/GT564UI/GT610UG/GT610US/
GT616UG)
LED933 6-502-325-11 LED SML-D12P8WT86TK (ILLUMINATION)
(GT560UE)
LED933 6-502-542-01 LED SCM015BC7TT86P (ILLUMINATION)
(GT560UI)
LED933 6-503-082-01 LED LNJ437W840S0 (ILLUMINATION)
(GT61UMS)
LED934 6-502-195-11 LED SML-D12D8WT86TQ (ILLUMINATION)
(GT610UG: AR)
LED935 6-502-193-11 LED SML-D12V8WT86TN (ILLUMINATION)
(GT560US/GT564UI/GT610UG/GT610US/
GT616UG)
LED935 6-502-325-11 LED SML-D12P8WT86TK (ILLUMINATION)
(GT560UE)
LED935 6-502-542-01 LED SCM015BC7TT86P (ILLUMINATION)
(GT560UI)
LED935 6-503-082-01 LED LNJ437W840S0 (ILLUMINATION)
(GT61UMS)
LED936 6-502-195-11 LED SML-D12D8WT86TQ (ILLUMINATION)
(GT610UG: AR)
LED937 6-502-193-11 LED SML-D12V8WT86TN (ILLUMINATION)
(GT560US/GT564UI/GT610UG/GT610US/
GT616UG)
LED937 6-502-325-11 LED SML-D12P8WT86TK (ILLUMINATION)
(GT560UE)
LED937 6-502-542-01 LED SCM015BC7TT86P (ILLUMINATION)
(GT560UI)
LED937 6-503-082-01 LED LNJ437W840S0 (ILLUMINATION)
(GT61UMS)
LED938 6-502-195-11 LED SML-D12D8WT86TQ (ILLUMINATION)
(GT610UG: AR)
LED939 6-502-193-11 LED SML-D12V8WT86TN (ILLUMINATION)
(GT560US/GT564UI/GT610UG/GT610US/
GT616UG)
LED939 6-502-325-11 LED SML-D12P8WT86TK (ILLUMINATION)
(GT560UE)
LED939 6-502-542-01 LED SCM015BC7TT86P (ILLUMINATION)
(GT560UI)
LED939 6-503-082-01 LED LNJ437W840S0 (ILLUMINATION)
(GT61UMS)
LED940 6-502-195-11 LED SML-D12D8WT86TQ (ILLUMINATION)
(GT610UG: AR)
LED941 6-502-193-11 LED SML-D12V8WT86TN (ILLUMINATION)
(GT560US/GT564UI/GT610UG/GT610US/
GT616UG)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
KEY
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
• Abbreviation
AR : Argentina model
EA : Saudi Arabia model
IND : Indian model
MX : Mexican model
RU : Russian model
To Next Page
