CDX-R3300/R3300S
Pin No. Pin Name I/O Pin Description
104 XLAT I Latch signal input
105 CLOK I Serial data transfer clock signal input
106 VDD — Digital power supply pin for internal
107 SENS O SENS signal output
108 SCLK I Clock signal input for SENS serial data read out
109 ATSK I/O Input/output for anti-shock
110 WFCK O WFCK signal output Not used in this set. (Open)
111 XUGF O XUGF signal output Not used in this set. (Open)
112 XPCK O XPCK signal output Not used in this set. (Open)
113 GFS O GFS signal output
114 C2PO O C2PO signal output
115 SCOR O Sub code sync signal output
116 VDD — Digital power supply pin for internal
117 C4M O 4.2336 MHz signal output Not used in this set. (Open)
118 WDCK O Word clock signal output Not used in this set. (Open)
119 COUT I/O Track count signal input/output Not used in this set. (Open)
120 NC — Not used. (Open)
