39
CDX-R3300/R3300S
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
•Abbreviation
CND : Canadian model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DISPLAY BOARD, COMPLETE
************************
1-780-120-11 CONDUCTIVE BOARD, CONNECTION
< CAPACITOR >
C551 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C552 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C553 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C958 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C959 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C960 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-794-312-21 PIN, CONNECTOR 12P
< DIODE >
D502 8-719-978-33 DIODE DTZ-TT11-6.8B
D503 8-719-978-33 DIODE DTZ-TT11-6.8B
D504 8-719-978-33 DIODE DTZ-TT11-6.8B
D521 8-719-988-61 DIODE 1SS355TE-17
D551 8-719-069-54 DIODE UDZS-TE17-5.1B
D552 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC501 6-705-180-01 IC LC75827W
IC502 6-600-321-01 IC KSM-401Y (IR)
IC906 6-705-374-01 IC MM3033DULE
< LIQUID CRYSTAL DISPLAY >
LCD501 1-805-451-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED501 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
LED502 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
LED503 8-719-082-38 LED CL-270SR-C-TS (DISC IND)
LED504 8-719-053-09 LED SML-310VT-T86 (2)
LED505 8-719-053-09 LED SML-310VT-T86 (1)
LED506 8-719-053-09 LED SML-310VT-T86 (SENS)
LED507 8-719-053-09 LED SML-310VT-T86 (ATT)
LED508 8-719-053-09 LED SML-310VT-T86 (6)
LED509 8-719-053-09 LED SML-310VT-T86 (5)
LED510 8-719-053-09 LED SML-310VT-T86 (4)
LED511 8-719-053-09 LED SML-310VT-T86 (3)
LED512 8-719-053-09 LED SML-310VT-T86 (BTM)
LED513 8-719-053-09 LED SML-310VT-T86 (DSPL)
LED514 8-719-053-09 LED SML-310VT-T86 (EQ3)
LED515 8-719-053-09 LED SML-310VT-T86 (OFF)
LED516 8-719-053-09 LED SML-310VT-T86 (m . –)
LED517 8-719-053-09 LED SML-310VT-T86 (+ > M)
LED518 8-719-053-09 LED SML-310VT-T86 (SCRL)
LED520 8-719-053-09 LED SML-310VT-T86 (–)
LED521 8-719-053-09 LED SML-310VT-T86 (+)
LED522 8-719-053-09 LED SML-310VT-T86 (SEL)
LED524 8-719-053-09 LED SML-310VT-T86 (SOURCE)
LED525 8-719-053-09 LED SML-310VT-T86 (MODE)
< TRANSISTOR >
Q501 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q502 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R501 1-216-819-11 METAL CHIP 680 5% 1/10W
R502 1-216-819-11 METAL CHIP 680 5% 1/10W
R503 1-216-819-11 METAL CHIP 680 5% 1/10W
R504 1-216-821-11 METAL CHIP 1K 5% 1/10W
R505 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R506 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R507 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R508 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R509 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R510 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R511 1-216-819-11 METAL CHIP 680 5% 1/10W
R512 1-216-819-11 METAL CHIP 680 5% 1/10W
R513 1-216-819-11 METAL CHIP 680 5% 1/10W
R514 1-216-821-11 METAL CHIP 1K 5% 1/10W
R515 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R516 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R517 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R518 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R519 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R531 1-216-809-11 METAL CHIP 100 5% 1/10W
R532 1-216-809-11 METAL CHIP 100 5% 1/10W
R533 1-216-809-11 METAL CHIP 100 5% 1/10W
R534 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R535 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R536 1-216-813-11 METAL CHIP 220 5% 1/10W
DISPLAY
To Next Page
