40
CDX-R3300/R3300S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R537 1-216-813-11 METAL CHIP 220 5% 1/10W
R551 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R552 1-216-815-11 METAL CHIP 330 5% 1/10W
R553 1-216-821-11 METAL CHIP 1K 5% 1/10W
R554 1-216-821-11 METAL CHIP 1K 5% 1/10W
R555 1-216-821-11 METAL CHIP 1K 5% 1/10W
R556 1-216-840-11 METAL CHIP 39K 5% 1/10W
R557 1-216-821-11 METAL CHIP 1K 5% 1/10W
R558 1-216-821-11 METAL CHIP 1K 5% 1/10W
R559 1-216-821-11 METAL CHIP 1K 5% 1/10W
R560 1-216-821-11 METAL CHIP 1K 5% 1/10W
R561 1-216-857-11 METAL CHIP 1M 5% 1/10W
R571 1-216-809-11 METAL CHIP 100 5% 1/10W
R572 1-216-809-11 METAL CHIP 100 5% 1/10W
R573 1-216-809-11 METAL CHIP 100 5% 1/10W
R574 1-216-809-11 METAL CHIP 100 5% 1/10W
R575 1-216-813-11 METAL CHIP 220 5% 1/10W
R576 1-216-813-11 METAL CHIP 220 5% 1/10W
R577 1-216-813-11 METAL CHIP 220 5% 1/10W
R578 1-216-813-11 METAL CHIP 220 5% 1/10W
R579 1-216-809-11 METAL CHIP 100 5% 1/10W
R580 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S501 1-786-653-11 SWITCH, TACTILE (OPEN/EJECT)
S502 1-786-653-11 SWITCH, TACTILE (OPEN/EJECT)
S503 1-771-884-31 SWITCH, TACTILE (OFF)
S504 1-771-884-31 SWITCH, TACTILE (SOURCE)
S505 1-771-884-31 SWITCH, TACTILE (MODE)
S506 1-771-884-31 SWITCH, TACTILE (SEL)
S507 1-771-884-31 SWITCH, TACTILE (VOLUME +)
S508 1-771-884-31 SWITCH, TACTILE (VOLUME –)
S509 1-771-884-31 SWITCH, TACTILE (ATT)
S510 1-771-884-31 SWITCH, TACTILE (SENS)
S511 1-771-884-31 SWITCH, TACTILE (1/ALBUM –)
S512 1-771-884-31 SWITCH, TACTILE (2/ALBUM +)
S513 1-771-884-31 SWITCH, TACTILE (SEEK + > M)
S514 1-771-884-31 SWITCH, TACTILE (SEEK m . –)
S515 1-771-884-31 SWITCH, TACTILE (EQ3)
S516 1-771-884-31 SWITCH, TACTILE (DSPL)
S517 1-771-884-31 SWITCH, TACTILE (BTM)
S518 1-771-884-31 SWITCH, TACTILE (6)
S519 1-771-884-31 SWITCH, TACTILE (5)
S520 1-771-884-31 SWITCH, TACTILE (4/SHUF)
S521 1-771-884-31 SWITCH, TACTILE (3/REP)
S522 1-771-884-31 SWITCH, TACTILE (SCRL)
S523 1-529-566-61 SWITCH, PUSH (1 KEY) (SHUTTER)
*************************************************************
A-3283-493-A MAIN BOARD, COMPLETE (including
SPEAKER BOARD) (US,CND)
A-3283-494-A MAIN BOARD, COMPLETE (including
SPEAKER BOARD) (E)
*********************
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C101 1-124-233-11 ELECT 10uF 20% 16V
C106 1-124-234-00 ELECT 22uF 20% 16V
C107 1-124-233-11 ELECT 10uF 20% 16V
C108 1-216-864-11 METAL CHIP 0 5% 1/10W
C109 1-124-233-11 ELECT 10uF 20% 16V
C111 1-124-233-11 ELECT 10uF 20% 16V
C113 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C303 1-216-864-11 METAL CHIP 0 5% 1/10W
C400 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C408 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C410 1-104-942-11 ELECT 1uF 20% 50V
C411 1-104-942-11 ELECT 1uF 20% 50V
C414 1-128-428-11 ELECT 10uF 20% 35V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-124-589-11 ELECT 47uF 20% 16V
C424 1-128-428-11 ELECT 10uF 20% 35V
C425 1-128-428-11 ELECT 10uF 20% 35V
C426 1-128-428-11 ELECT 10uF 20% 35V
C428 1-128-428-11 ELECT 10uF 20% 35V
C430 1-126-947-11 ELECT 47uF 20% 16V
C435 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C436 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C437 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C438 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C440 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C441 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C444 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C446 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C447 1-124-257-00 ELECT 2.2uF 20% 50V
C452 1-128-428-11 ELECT 10uF 20% 35V
C453 1-128-428-11 ELECT 10uF 20% 35V
C600 1-216-864-11 METAL CHIP 0 5% 1/10W
C618 1-126-786-11 ELECT 47uF 20% 16V
C619 1-124-247-61 ELECT 10uF 20% 35V
C620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C701 1-124-584-00 ELECT 100uF 20% 10V
C704 1-124-584-00 ELECT 100uF 20% 10V
C705 1-124-584-00 ELECT 100uF 20% 10V
C706 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C707 1-124-584-00 ELECT 100uF 20% 10V
C709 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C802 1-124-589-11 ELECT 47uF 20% 16V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C809 1-124-584-00 ELECT 100uF 20% 10V
C810 1-125-701-11 DOUBLE LAYERS 0.047F 5.5V
C812 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C813 1-124-584-00 ELECT 100uF 20% 10V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C816 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C817 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C818 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C820 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C821 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
DISPLAY MAIN
To Next Page
