Sony CDX-R3300 - Page 41

41
CDX-R3300/R3300S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C823 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C824 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C825 1-124-584-00 ELECT 100uF 20% 10V
C908 1-126-960-11 ELECT 1uF 20% 50V
C909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C922 1-131-868-81 ELECT 3300uF 20% 16V
< CONNECTOR >
CN751 1-817-536-11 CONNECTOR, BOARD TO BOARD 28P
CNP800 1-794-311-21 PLUG, CONNECTOR 12P
CNP901 1-774-701-21 PIN, CONNECTOR 16P
< JACK >
CNP900 1-764-270-21 JACK (REMOTE IN) (E)
< DIODE >
D400 8-719-988-61 DIODE 1SS355TE-17
D600 8-719-069-55 DIODE UDZS-TE17-5.6B
D701 8-719-988-61 DIODE 1SS355TE-17
D702 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
D804 8-719-050-84 DIODE RB441Q-40T-77
D808 8-719-977-12 DIODE DTZ6.8B
D810 8-719-988-61 DIODE 1SS355TE-17 (E)
D811 8-719-109-97 DIODE RD6.8ES-B2
D812 8-719-109-97 DIODE RD6.8ES-B2
D813 8-719-109-97 DIODE RD6.8ES-B2
D814 8-719-109-97 DIODE RD6.8ES-B2
D815 8-719-109-97 DIODE RD6.8ES-B2
D816 8-719-109-97 DIODE RD6.8ES-B2
D817 8-719-109-97 DIODE RD6.8ES-B2
D818 8-719-071-34 DIODE RB521S-30-TE61
D820 8-719-991-33 DIODE 1SS133T-77
D855 8-719-071-34 DIODE RB521S-30-TE61
D856 8-719-071-34 DIODE RB521S-30-TE61
D902 8-719-053-18 DIODE 1SR154-400TE-25
D903 8-719-053-18 DIODE 1SR154-400TE-25
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
D906 8-719-200-82 DIODE 11ES2
D907 8-719-200-82 DIODE 11ES2
D908 8-719-200-82 DIODE 11ES2
D909 8-719-200-82 DIODE 11ES2
D912 8-719-083-66 DIODE UDZS-TE17-18B
D914 8-719-977-12 DIODE DTZ6.8B
D915 8-719-056-84 DIODE UDZ-TE-17-7.5B
D916 8-719-200-82 DIODE 11ES2
D917 8-719-200-82 DIODE 11ES2
D919 8-719-049-38 DIODE 1N5404TU
D921 8-719-200-82 DIODE 11ES2
D922 8-719-200-82 DIODE 11ES2
< IC >
IC100 6-705-360-01 IC TDA8588BJ/N2
IC401 6-705-372-01 IC BD3808FS-FE2
IC801 6-803-821-01 IC MB90487PF-G-104-BNDE1
IC802 8-759-659-13 IC PST3428UL
< JUMPER RESISTOR >
JR5 1-216-864-11 METAL CHIP 0 5% 1/10W
JR6 1-216-864-11 METAL CHIP 0 5% 1/10W
JR7 1-216-864-11 METAL CHIP 0 5% 1/10W
JR10 1-216-864-11 METAL CHIP 0 5% 1/10W
JR103 1-216-864-11 METAL CHIP 0 5% 1/10W
< COIL >
L400 1-414-398-11 INDUCTOR 10uH
L602 1-414-394-41 INDUCTOR 2.2uH
L700 1-410-501-11 INDUCTOR 2.2uH
L701 1-410-501-11 INDUCTOR 2.2uH
L702 1-410-509-11 INDUCTOR 10uH
L703 1-216-295-11 SHORT CHIP 0
L900 1-456-617-11 COIL, CHOKE 250uH
< JACK >
PJ401 1-774-698-11 JACK, PIN 2P (AUDIO OUT REAR)
PJ601 1-793-598-11 JACK (ANTENNA)
< TRANSISTOR >
Q400 8-729-038-71 TRANSISTOR KRC107S
Q401 8-729-038-55 TRANSISTOR KRA103S
Q402 6-550-752-01 TRANSISTOR DTC614TKT146
Q403 6-550-752-01 TRANSISTOR DTC614TKT146
Q404 6-550-752-01 TRANSISTOR DTC614TKT146
Q405 6-550-752-01 TRANSISTOR DTC614TKT146
Q406 6-550-752-01 TRANSISTOR DTC614TKT146
Q407 6-550-752-01 TRANSISTOR DTC614TKT146
Q601 8-729-920-85 TRANSISTOR 2SD1664-QR
Q800 8-729-038-55 TRANSISTOR KRA103S
Q900 8-729-034-51 TRANSISTOR KTC3875
Q902 8-729-038-67 TRANSISTOR KRC102S
Q906 8-729-034-51 TRANSISTOR KTC3875
Q907 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R404 1-216-809-11 METAL CHIP 100 5% 1/10W
R405 1-216-809-11 METAL CHIP 100 5% 1/10W
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R409 1-216-839-11 METAL CHIP 33K 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R412 1-216-809-11 METAL CHIP 100 5% 1/10W
R414 1-216-809-11 METAL CHIP 100 5% 1/10W
R415 1-216-809-11 METAL CHIP 100 5% 1/10W
R416 1-216-809-11 METAL CHIP 100 5% 1/10W
R417 1-216-809-11 METAL CHIP 100 5% 1/10W
R418 1-216-841-11 METAL CHIP 47K 5% 1/10W
R419 1-216-841-11 METAL CHIP 47K 5% 1/10W
R420 1-216-841-11 METAL CHIP 47K 5% 1/10W
R421 1-216-841-11 METAL CHIP 47K 5% 1/10W
R424 1-216-805-11 METAL CHIP 47 5% 1/10W
R427 1-216-809-11 METAL CHIP 100 5% 1/10W
R429 1-247-807-31 CARBON 100 5% 1/4W
R431 1-247-807-31 CARBON 100 5% 1/4W
R432 1-216-809-11 METAL CHIP 100 5% 1/10W
MAIN
