– 57 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R570 1-249-425-11 CARBON 4.7K 5% 1/4W
R571 1-249-425-11 CARBON 4.7K 5% 1/4W
R578 1-249-429-11 CARBON 10K 5% 1/4W
R579 1-249-429-11 CARBON 10K 5% 1/4W
R580 1-249-417-11 CARBON 1K 5% 1/4W
R581 1-247-895-00 CARBON 470K 5% 1/4W
R582 1-247-895-00 CARBON 470K 5% 1/4W
R583 1-249-425-11 CARBON 4.7K 5% 1/4W
R584 1-249-425-11 CARBON 4.7K 5% 1/4W
R585 1-249-425-11 CARBON 4.7K 5% 1/4W
R586 1-249-425-11 CARBON 4.7K 5% 1/4W
R587 1-249-437-11 CARBON 47K 5% 1/4W
R588 1-249-425-11 CARBON 4.7K 5% 1/4W
R589 1-247-843-11 CARBON 3.3K 5% 1/4W
R590 1-249-425-11 CARBON 4.7K 5% 1/4W
R591 1-247-878-00 CARBON 91K 5% 1/4W
R592 1-249-425-11 CARBON 4.7K 5% 1/4W
R593 1-249-431-11 CARBON 15K 5% 1/4W
R594 1-249-437-11 CARBON 47K 5% 1/4W
R595 1-249-417-11 CARBON 1K 5% 1/4W
R596 1-249-429-11 CARBON 10K 5% 1/4W
R597 1-249-417-11 CARBON 1K 5% 1/4W
R598 1-249-437-11 CARBON 47K 5% 1/4W
R599 1-249-425-11 CARBON 4.7K 5% 1/4W
R701 1-249-440-11 CARBON 82K 5% 1/4W
R702 1-249-441-11 CARBON 100K 5% 1/4W
R703 1-249-441-11 CARBON 100K 5% 1/4W
R704 1-249-441-11 CARBON 100K 5% 1/4W
R705 1-249-441-11 CARBON 100K 5% 1/4W
R706 1-249-440-11 CARBON 82K 5% 1/4W
R707 1-247-887-00 CARBON 220K 5% 1/4W
R709 1-247-883-00 CARBON 150K 5% 1/4W
R710 1-247-885-00 CARBON 180K 5% 1/4W
R711 1-247-883-00 CARBON 150K 5% 1/4W
R712 1-247-891-00 CARBON 330K 5% 1/4W
R714 1-249-429-11 CARBON 10K 5% 1/4W
R715 1-249-429-11 CARBON 10K 5% 1/4W
R716 1-247-852-11 CARBON 7.5K 5% 1/4W
R717 1-247-903-00 CARBON 1M 5% 1/4W
R718 1-247-899-11 CARBON 680K 5% 1/4W
R719 1-249-393-11 CARBON 10 5% 1/4W
R720 1-249-431-11 CARBON 15K 5% 1/4W
R721 1-249-435-11 CARBON 33K 5% 1/4W
R722 1-247-886-11 CARBON 200K 5% 1/4W
R723 1-247-896-11 CARBON 510K 5% 1/4W
R724 1-249-439-11 CARBON 68K 5% 1/4W
R725 1-247-883-00 CARBON 150K 5% 1/4W
R726 1-247-883-00 CARBON 150K 5% 1/4W
R727 1-249-437-11 CARBON 47K 5% 1/4W
R728 1-247-885-00 CARBON 180K 5% 1/4W
R729 1-249-430-11 CARBON 12K 5% 1/4W
R730 1-249-435-11 CARBON 33K 5% 1/4W
R731 1-247-863-00 CARBON 22K 5% 1/4W
R734 1-247-843-11 CARBON 3.3K 5% 1/4W
R735 1-249-430-11 CARBON 12K 5% 1/4W
R736 1-247-863-00 CARBON 22K 5% 1/4W
R738 1-249-435-11 CARBON 33K 5% 1/4W
R741 1-249-417-11 CARBON 1K 5% 1/4W
R742 1-249-417-11 CARBON 1K 5% 1/4W
R744 1-249-417-11 CARBON 1K 5% 1/4W
R745 1-249-417-11 CARBON 1K 5% 1/4W
R746 1-249-417-11 CARBON 1K 5% 1/4W
R747 1-249-428-11 CARBON 8.2K 5% 1/4W
R748 1-247-890-11 CARBON 300K 5% 1/4W
R757 1-249-417-11 CARBON 1K 5% 1/4W
R758 1-249-437-11 CARBON 47K 5% 1/4W
R760 1-249-437-11 CARBON 47K 5% 1/4W
R764 1-247-843-11 CARBON 3.3K 5% 1/4W
R765 1-249-417-11 CARBON 1K 5% 1/4W
R766 1-249-429-11 CARBON 10K 5% 1/4W
R768 1-247-903-00 CARBON 1M 5% 1/4W
R771 1-249-429-11 CARBON 10K 5% 1/4W
R772 1-247-887-00 CARBON 220K 5% 1/4W
R780 1-249-430-11 CARBON 12K 5% 1/4W
R781 1-249-430-11 CARBON 12K 5% 1/4W
R782 1-249-430-11 CARBON 12K 5% 1/4W
R790 1-249-430-11 CARBON 12K 5% 1/4W
R791 1-249-430-11 CARBON 12K 5% 1/4W
R792 1-249-430-11 CARBON 12K 5% 1/4W
R951 1-249-437-11 CARBON 47K 5% 1/4W
R952 1-249-417-11 CARBON 1K 5% 1/4W
R954 1-247-815-00 CARBON 220 5% 1/4W
R955 1-247-807-11 CARBON 100 5% 1/4W
R958 1-247-815-00 CARBON 220 5% 1/4W
R960 1-247-807-11 CARBON 100 5% 1/4W
R961 1-249-413-11 CARBON 470 5% 1/4W
R962 1-249-437-11 CARBON 47K 5% 1/4W
R963 1-249-417-11 CARBON 1K 5% 1/4W
< TRANSFORMER >
T301 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
< VIBRATOR >
X501 1-781-357-11 VIBRATOR, CERAMIC (4.19MHz)
X502 1-767-697-11 VIBRATOR, CRYSTAL (32.768kHz)
X701 1-577-253-11 VIBRATOR, CERAMIC (16.9344MHz)
*************************************************************
* 1-672-724-11 PRIMARY BOARD
***************
< AC INLET >
! CNJ901 1-540-009-11 INLET, AC ( ⁄ AC IN)
< CABLE HOLDER >
* KH902 1-565-384-11 HOLDER, CABLE 3P
*************************************************************
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
PRIMARYMAIN
