– 58 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECONDARY SOUND
* A-3322-028-A SECONDARY BOARD, COMPLETE
***************************
1-533-233-31 HOLDER, FUSE
< CAPACITOR >
C901 1-101-005-00 CERAMIC 22000PF 50V
C902 1-101-005-00 CERAMIC 22000PF 50V
C903 1-101-005-00 CERAMIC 22000PF 50V
C904 1-101-005-00 CERAMIC 22000PF 50V
C907 1-162-294-31 CERAMIC 0.001uF 10% 50V
C908 1-124-907-11 ELECT 10uF 20% 50V
C909 1-126-768-11 ELECT 2200uF 20% 16V
C910 1-136-165-00 FILM 0.1uF 5% 50V
< CONNECTOR >
CNP901 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
CNP902 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
* CNP906 1-580-155-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D404 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D407 8-719-991-33 DIODE 1SS133T-77
D408 8-719-991-33 DIODE 1SS133T-77
D901 8-719-046-07 DIODE 2A02M
D902 8-719-046-07 DIODE 2A02M
D903 8-719-046-07 DIODE 2A02M
D904 8-719-046-07 DIODE 2A02M
D905 8-719-991-33 DIODE 1SS133T-77
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-991-33 DIODE 1SS133T-77
D908 8-719-991-33 DIODE 1SS133T-77
D909 8-719-991-33 DIODE 1SS133T-77
D910 8-719-991-33 DIODE 1SS133T-77
< FUSE >
! F902 1-576-109-11 FUSE (5A/125V)
< IC >
IC901 8-759-479-70 IC S-81250SGY-B
< COIL >
JW915 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q401 8-729-036-77 TRANSISTOR KRC107M
Q402 8-729-036-77 TRANSISTOR KRC107M
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
Q404 8-729-036-77 TRANSISTOR KRC107M
Q405 8-729-037-34 TRANSISTOR KRA107M
Q406 8-729-036-80 TRANSISTOR KRC110M
Q407 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q408 8-729-036-77 TRANSISTOR KRC107M
Q409 8-729-036-77 TRANSISTOR KRC107M
< RESISTOR >
R401 1-249-441-11 CARBON 100K 5% 1/4W
R404 1-249-441-11 CARBON 100K 5% 1/4W
R405 1-249-441-11 CARBON 100K 5% 1/4W
R406 1-247-815-00 CARBON 220 5% 1/4W
R407 1-249-429-11 CARBON 10K 5% 1/4W
R409 1-247-895-00 CARBON 470K 5% 1/4W
R902 1-249-387-11 CARBON 3.3 5% 1/4W
R903 1-247-807-11 CARBON 100 5% 1/4W
R904 1-247-807-11 CARBON 100 5% 1/4W
R906 1-247-899-11 CARBON 680K 5% 1/4W
R907 1-247-887-00 CARBON 220K 5% 1/4W
R908 1-249-429-11 CARBON 10K 5% 1/4W
*************************************************************
* A-3322-036-A SOUND BOARD, COMPLETE
***********************
< CAPACITOR >
C142 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C143 1-126-791-11 ELECT 10uF 20% 16V
C144 1-127-886-21 CERAMIC 0.068uF 10% 50V
C145 1-127-886-21 CERAMIC 0.068uF 10% 50V
C146 1-127-876-21 CERAMIC 0.01uF 10% 50V
C147 1-115-871-11 ELECT 1uF 20% 50V
C242 1-162-301-11 CERAMIC 0.0015uF 20% 16V
C243 1-126-791-11 ELECT 10uF 20% 16V
C244 1-127-886-21 CERAMIC 0.068uF 10% 50V
C245 1-127-886-21 CERAMIC 0.068uF 10% 50V
C246 1-127-876-21 CERAMIC 0.01uF 10% 50V
C247 1-115-871-11 ELECT 1uF 20% 50V
C333 1-126-785-11 ELECT 47uF 20% 10V
C334 1-115-872-11 ELECT 2.2uF 20% 50V
C335 1-126-791-11 ELECT 10uF 20% 16V
C336 1-126-791-11 ELECT 10uF 20% 16V
C337 1-124-635-00 ELECT 220uF 20% 6.3V
C338 1-161-494-00 CERAMIC 0.022uF 25V
C340 1-162-294-31 CERAMIC 0.001uF 10% 50V
C341 1-162-294-31 CERAMIC 0.001uF 10% 50V
C342 1-162-294-31 CERAMIC 0.001uF 10% 50V
C343 1-161-494-00 CERAMIC 0.022uF 25V
C347 1-126-382-11 ELECT 100uF 20% 6.3V
< CONNECTOR >
* CNP311 1-766-594-11 PIN, CONNECTOR (PC BOARD) 11P
To Next Page
