– 59 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER
< IC >
IC302 8-759-432-41 IC BH3854AS
< TRANSISTOR >
Q308 8-729-036-58 TRANSISTOR KRC102M-AT
Q309 8-729-036-80 TRANSISTOR KRC110M
< RESISTOR >
R141 1-249-425-11 CARBON 4.7K 5% 1/4W
R142 1-249-426-11 CARBON 5.6K 5% 1/4W
R241 1-249-425-11 CARBON 4.7K 5% 1/4W
R242 1-249-426-11 CARBON 5.6K 5% 1/4W
R326 1-249-399-11 CARBON 33 5% 1/4W
R338 1-249-417-11 CARBON 1K 5% 1/4W
R339 1-249-417-11 CARBON 1K 5% 1/4W
R340 1-249-417-11 CARBON 1K 5% 1/4W
R344 1-247-863-00 CARBON 22K 5% 1/4W
*************************************************************
* A-3322-035-A TUNER BOARD, COMPLETE
***********************
< CAPACITOR >
C8 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C10 1-124-903-11 ELECT 1uF 20% 50V
C11 1-127-888-21 CERAMIC 0.1uF 10% 50V
C12 1-126-963-11 ELECT 4.7uF 20% 50V
C13 1-162-306-11 CERAMIC 0.01uF 20% 16V
C14 1-127-879-21 CERAMIC 0.018uF 10% 50V
C15 1-127-879-21 CERAMIC 0.018uF 10% 50V
C16 1-124-903-11 ELECT 1uF 20% 50V
C17 1-124-903-11 ELECT 1uF 20% 50V
C18 1-104-666-11 ELECT 220uF 20% 10V
C20 1-127-888-21 CERAMIC 0.1uF 10% 50V
C21 1-124-903-11 ELECT 1uF 20% 50V
C22 1-127-888-21 CERAMIC 0.1uF 10% 50V
C23 1-124-903-11 ELECT 1uF 20% 50V
C24 1-162-288-31 CERAMIC 330PF 10% 50V
C25 1-162-600-11 CERAMIC 0.0047uF 20% 16V
C27 1-162-306-11 CERAMIC 0.01uF 20% 16V
C30 1-162-306-11 CERAMIC 0.01uF 20% 16V
C31 1-102-514-11 CERAMIC 22PF 5% 50V
C33 1-162-306-11 CERAMIC 0.01uF 20% 16V
C34 1-162-294-31 CERAMIC 0.001uF 10% 50V
C35 1-127-888-21 CERAMIC 0.1uF 10% 50V
C40 1-127-888-21 CERAMIC 0.1uF 10% 50V
C41 1-102-821-00 CERAMIC 360PF 5% 50V
C42 1-162-198-31 CERAMIC 8.2PF 10% 50V
C43 1-162-282-31 CERAMIC 100PF 10% 50V
C44 1-127-888-21 CERAMIC 0.1uF 10% 50V
C45 1-162-306-11 CERAMIC 0.01uF 20% 16V
C51 1-162-203-31 CERAMIC 15PF 5% 50V
C52 1-162-201-31 CERAMIC 12PF 5% 50V
C53 1-136-171-00 FILM 0.33uF 5% 50V
C54 1-124-472-11 ELECT 470uF 20% 10V
C55 1-162-282-31 CERAMIC 100PF 10% 50V
C56 1-162-294-31 CERAMIC 0.001uF 10% 50V
C57 1-162-294-31 CERAMIC 0.001uF 10% 50V
C58 1-162-282-31 CERAMIC 100PF 10% 50V
C60 1-162-294-31 CERAMIC 0.001uF 10% 50V
C62 1-162-306-11 CERAMIC 0.01uF 20% 16V
C63 1-162-282-31 CERAMIC 100PF 10% 50V
C64 1-162-282-31 CERAMIC 100PF 10% 50V
C65 1-162-282-31 CERAMIC 100PF 10% 50V
C77 1-137-370-11 FILM 0.01uF 5% 50V
C80 1-162-306-11 CERAMIC 0.01uF 20% 16V
C91 1-162-306-11 CERAMIC 0.01uF 20% 16V
C92 1-162-306-11 CERAMIC 0.01uF 20% 16V
C93 1-162-306-11 CERAMIC 0.01uF 20% 16V
C95 1-162-294-31 CERAMIC 0.001uF 10% 50V
C96 1-162-282-31 CERAMIC 100PF 10% 50V
C98 1-162-282-31 CERAMIC 100PF 10% 50V
< FILTER >
CF1 1-760-738-61 FILTER, CERAMIC
CF3 1-781-171-11 DISCRIMINATOR, CERAMIC
CF4 1-781-344-11 FILTER, AM CERAMIC
< CONNECTOR >
CNP1 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
* CNP2 1-580-159-11 PIN, CONNECTOR (PC BOARD) 7P
< TRIMMER >
CT1 1-141-603-11 CAP, ADJ 20PF
CT3 1-141-601-11 CAP, ADJ 10PF
< DIODE >
D1 8-719-050-72 DIODE KV1370NT
D2 8-719-050-72 DIODE KV1370NT
D3 8-719-050-69 DIODE KV1520N
D5 8-719-923-93 DIODE MTZJ-T-77-16C
D6 8-719-991-33 DIODE 1SS133T-77
D7 8-719-991-33 DIODE 1SS133T-77
D10 8-719-991-33 DIODE 1SS133T-77
D11 8-719-991-33 DIODE 1SS133T-77
< BPF >
FL1 1-236-711-21 FILTER, BAND PASS
< IC >
IC1 8-759-549-84 IC TA2104AN
IC2 8-759-549-57 IC LC72137-D
< COIL >
L1 1-409-905-31 COIL, FM RF
SOUND
