– 60 –
Ref. No. Part No. Description Remark
TUNER
Sony Corporation
Personal Audio Company
9-927-121-11
99E047018-1
Printed in Singapore C1999. 5
Published by General Engineering Dept.
CFD-S39
Ref. No. Part No. Description Remark
L2 1-409-904-31 COIL, FM OSC
L3 1-501-923-21 ANTENNA, FERRITE-ROD (AM)
L4 1-411-234-41 COIL, AM OSC
L11 1-414-142-11 INDUCTOR 1uH
L91 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q12 8-729-036-77 TRANSISTOR KRC107M
Q13 8-729-036-77 TRANSISTOR KRC107M
< RESISTOR >
R1 1-249-411-11 CARBON 330 5% 1/4W
R3 1-249-429-11 CARBON 10K 5% 1/4W
R4 1-249-429-11 CARBON 10K 5% 1/4W
R10 1-247-791-00 CARBON 22 5% 1/4W
R11 1-247-843-11 CARBON 3.3K 5% 1/4W
R12 1-249-437-11 CARBON 47K 5% 1/4W
R13 1-249-421-11 CARBON 2.2K 5% 1/4W
R24 1-247-815-00 CARBON 220 5% 1/4W
R25 1-249-393-11 CARBON 10 5% 1/4W
R30 1-249-431-11 CARBON 15K 5% 1/4W
R31 1-247-843-11 CARBON 3.3K 5% 1/4W
R32 1-249-441-11 CARBON 100K 5% 1/4W
R33 1-247-887-00 CARBON 220K 5% 1/4W
R35 1-249-429-11 CARBON 10K 5% 1/4W
R40 1-247-887-00 CARBON 220K 5% 1/4W
R41 1-249-429-11 CARBON 10K 5% 1/4W
R50 1-249-417-11 CARBON 1K 5% 1/4W
R51 1-249-429-11 CARBON 10K 5% 1/4W
R53 1-249-430-11 CARBON 12K 5% 1/4W
R54 1-247-843-11 CARBON 3.3K 5% 1/4W
R56 1-249-416-11 CARBON 820 5% 1/4W
R58 1-249-417-11 CARBON 1K 5% 1/4W
R59 1-249-417-11 CARBON 1K 5% 1/4W
R60 1-249-417-11 CARBON 1K 5% 1/4W
R61 1-249-417-11 CARBON 1K 5% 1/4W
R64 1-247-863-00 CARBON 22K 5% 1/4W
R91 1-249-417-11 CARBON 1K 5% 1/4W
R92 1-249-417-11 CARBON 1K 5% 1/4W
R93 1-249-417-11 CARBON 1K 5% 1/4W
R94 1-249-417-11 CARBON 1K 5% 1/4W
R95 1-249-417-11 CARBON 1K 5% 1/4W
< TRANSFORMER >
T1 1-433-741-11 TRANSFORMER, IF
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
MISCELLANEOUS
***************
8 1-790-379-11 WIRE (FLAT TYPE) (10 CORE)
103 1-452-899-11 MAGNET
122 1-777-955-11 WIRE (FLAT TYPE) (16 CORE)
186 1-670-207-11 TRANSLATION (HEAD) BOARD
! 351 8-848-483-05 PICK-UP, OPTICAL KSS-213C/Q-RP
356 X-2626-202-1 CHASSIS ASSY (MB), MOTOR (SPINDLE)
(INCLUDING M701)
ANT1 1-501-891-11 ANTENNA, TELESCOPIC
! F902 1-576-109-11 FUSE (5A/125V)
HE301 1-500-338-11 HEAD, MAGNETIC (ERASE)
HRP301 1-543-872-11 HEAD, MAGNETIC (REC/PB)
M301 A-3320-436-A MOTOR ASSY (CAPSTAN/REEL)
M702 X-2625-769-1 GEAR ASSY (MB), MOTOR (SLED)
S301 1-571-556-11 SWITCH, LEAF (DIR)
S302 1-571-556-11 SWITCH, LEAF (DIR MODE)
S303 1-571-556-11 SWITCH, LEAF (TAPE PLAY)
S304 1-692-302-11 SWITCH, LEAF (MOTOR ON/OFF)
S305 1-692-302-11 SWITCH, LEAF (REC (FWD))
S501 1-692-960-11 SWITCH, PUSH (1 KEY) (CD DOOR
OPEN/CLOSE)
SP301 1-529-185-11 SPEAKER (10cm) (L-CH)
SP302 1-529-185-11 SPEAKER (10cm) (R-CH)
! T901 1-433-638-21 TRANSFORMER, POWER
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
! 1-783-878-11 CORD, POWER
3-027-153-11 LID, BATTERY CASE (for RMT-CS38A)
3-865-707-11 MANUAL, INSTRUCTION (ENGLISH)
A-3250-910-A RMT-CS38A//C SET
*************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#3 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#4 7-685-781-09 SCREW +PTT 2X4 (S)
#5 7-682-548-04 SCREW +B 3X8
#6 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#7 7-621-772-10 SCREW +B 2X4
#8 7-685-782-01 SCREW +PTT 2X5 (S)
#9 7-685-132-19 SCREW +BTP 2.6X5 TYPE2 N-S
