NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number specified.
r
ELECTRICAL PARTS LIST (Service Manual See page 39 to 43)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAINCD MOTOR
BATTAC INLET
* 1-665-034-13 AC INLET BOARD (C&SA)
* 1-665-043-13 AC INLET BOARD (KR,AUS,SP)
* 1-665-043-23 AC INLET BOARD (EA,JE)
**************
1-533-217-31 HOLDER, FUSE (EA, JE)
< CAPACITOR >
C907 1-162-294-31 CERAMIC 0.001uF 10%
< CONNECTOR >
* CN905 1-564-752-11 PIN, CONNECTOR (WITH LOCK) 3P (EA, JE)
< FUSE >
! F901 1-532-235-00 FUSE, TIME LAG (T0.315AL/250V) (EA,JE)
< JACK >
! J901 1-526-818-11 INLET, AC (⁄AC IN) (C&SA)
! J901 1-526-838-11 INLET, AC 2P (⁄AC IN) (EXCEPT C&SA)
************************************************************
* 1-665-033-13 BATT BOARD (C&SA)
* 1-665-033-23 BATT BOARD (EXCEPT C&SA)
***********
************************************************************
1-639-678-12 CD MOTOR BOARD
****************
< CONNECTOR >
CNP707 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P
< SWITCH >
S701 1-572-085-11 SWITCH, LEAF (LIMIT)
************************************************************
* A-3306-706-A MAIN BOARD, COMPLETE (JE)
* A-3306-758-A MAIN BOARD, COMPLETE (KR,SP)
* A-3306-986-A MAIN BOARD, COMPLETE (C&SA)
* A-3321-130-A MAIN BOARD, COMPLETE (AUS)
* A-3321-141-A MAIN BOARD, COMPLETE (EA)
*********************
3-009-192-01 GEAR, TUNING CAPACITOR
3-009-194-01 KNOB (FUN) (E,EA)
3-009-194-21 KNOB (FUN) (EXCEPT C&SA,EA)
7-621-770-99 SCREW +P 2.6X8 (EXCEPT JE)
7-621-773-95 SCREW +B 2.6X6 (JE)
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C1 1-162-215-31 CERAMIC 47PF 5% 50V
C2 1-162-306-11 CERAMIC 0.01uF 20% 16V
C3 1-104-664-11 ELECT 47uF 20% 10V
C5 1-162-205-31 CERAMIC 18PF 5% 50V
C6 1-102-951-00 CERAMIC 15PF 5% 50V (JE)
C6 1-102-960-00 CERAMIC 24PF 5% 50V
(C&SA)
C6 1-102-962-00 CERAMIC 30PF 5% 50V
(SP,KR)
C6 1-102-961-00 CERAMIC 27PF 5% 50V
(EA,AUS)
C7 1-102-943-00 CERAMIC 6.0PF ± 0.5PF 50V
C8 1-162-193-31 CERAMIC 3.3PF 10% 50V
C9 1-162-306-11 CERAMIC 0.01uF 20% 16V
C10 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-126-963-11 ELECT 4.7uF 20% 50V
C12 1-124-903-11 ELECT 1uF 20% 50V
C13 1-104-664-11 ELECT 47uF 20% 10V
C14 1-104-664-11 ELECT 47uF 20% 10V
C15 1-162-306-11 CERAMIC 0.01uF 20% 16V
C16 1-126-961-11 ELECT 2.2uF 20% 50V
C17 1-124-443-00 ELECT 100uF 20% 10V
C18 1-162-840-11 CERAMIC 0.012uF 10% 16V
(EXCEPT C&SA)
C18 1-162-842-11 CERAMIC 0.018uF 10% 16V
(C&SA)
C19 1-162-840-11 CERAMIC 0.012uF 10% 16V
(EXCEPT C&SA)
C19 1-162-842-11 CERAMIC 0.018uF 10% 16V
(C&SA)
C20 1-162-306-11 CERAMIC 0.01uF 20% 16V
C21 1-162-203-31 CERAMIC 15PF 5% 50V
C22 1-124-903-11 ELECT 1uF 20% 50V
C23 1-124-902-00 ELECT 0.47uF 20% 50V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C25 1-162-294-31 CERAMIC 0.001uF 10% 50V
C26 1-162-294-31 CERAMIC 0.001uF 10% 50V
• Abbreviation
KR : Korean
EA : Saudi Arabia
AUS : Australian
SP : Singapore
JE : Tourist
C&SA : Central & South America
