15
CFM-20
• All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or
less are not indicated except for electrolytics and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise specified.
• f : internal component.
• C : panel designation.
Note: The components identified by mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number specified.
• A : B+ Line.
• H : adjustment for repair.
• Power voltage is dc 6V and fed with regulated dc power supply
from external power voltage jack.
• Voltages are dc with respect to ground under no-signal (detuned)
conditions.
no mark : FM
( ) : AM (RADIO SECTION), PLAY (TAPE SECTION)
< > : MIC REC
[ ] : RADIO REC
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production toler-
ances.
• Signal path.
F : FM
f : AM
E : PB
a : REC
N : MIC
• Abbreviation
SP : Singapore
HK : Hong Kong
AR : Argentina
MX : Mexican
IT : Italian
TW : Taiwan
C&SA : Central and South America
CET : East European & Russian
Note on schematic Diagram: MAIN SECTION (1/2), (2/2)
