Sony CFM-20

4
CFM-20
2-3. RECORD/PLAYBACK HEAD (HRP101), REEL/CAPSTAN MOTOR (M101), BELT
2-4. JACK BOARD (AEP, UK, IT, CET, HK, SP, AR model), MAIN BOARD
1
Screws Tapping+B
(+PTT 2X5(s))
MD ASSY
4 Record/playback
head (HRP101)
8 Reel/capstan
motor (M101)
MD ASSY
M101
Belt
Flywheel ASS
Y
• Attaching belt
6 Spring, Compr
3
Screws
+ PTT 2X 5
7
Screws + P2.6X 5
9 Belt
5
Lug (T), plate
2 Guide, tape
7
8
6
1
2
0
4
Screw
(+ BVTP 3X10)
3
Screw
(+ BVTP 3X10)
Jack board
9 CNP901
Main board
MCabinet (rear)
knob (VOL)
knob (FUN)
Chasis
5
Screw
(+ BVTP 3X10)
