Specifications
Amplifier section
For the U.S. model
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 8-ohm loads both channels driven, from
90 - 15,000 Hz; rated 15 watts per channel
minimum RMS power, with no more than 0.9%
total harmonic distortion from 250 milliwatts to
rated output.
North American model:
Continuous RMS power output (reference):
17 + 17 W
(8 ohms at 1 kHz, 10% THD)
European model:
DIN power output (rated): 15 + 15 W
(8 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
17 + 17 W
(8 ohms at 1 kHz, 10% THD)
Music power output (reference):
35 + 35 W
Other models:
The following measured at 230 V AC, 60 Hz
DIN power output (rated): 15 + 15 W
(8 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
17 + 17 W
(8 ohms at 1 kHz, 10% THD)
Inputs
MD IN (phono jacks): Sensitivity 1,000 mV, impedance
47 kilohms
Outputs
MD OUT (phono jacks): Sensitivity 500 mV, impedance
1 kilohm
CD DIGITAL OUT OPTICAL:
Optical
PHONES (stereo phone jack):
Accepts headphones with an
impedance of 8 ohms or more
SPEAKER: Accepts impedance of 8 to
16 ohms
CD player section
System Compact disc and digital audio
system
Laser Semiconductor laser
(λ = 780 nm)
Emission duration: continuous
Laser output MAX 44.6
µ
W*
* This output is the value
measured at a distance of
200 mm from the objective
lens surface on the Optical
Pick-up Block with 7 mm
aperture.
Wavelength 780 - 790 nm
Frequency response 2 Hz - 20 kHz (±0.5 dB)
Tape player section
Recording system 4-track 2-channel stereo
Frequency response (DOLBY NR OFF)
50 - 13,000 Hz (±3 dB), using a
Sony TYPE I cassette
50 - 14,000 Hz (±3 dB),
using a Sony TYPE II cassette
Wow and flutter ±0.15% W. Peak (IEC)
0.1% W. RMS (NAB)
±0.2% W. Peak (DIN)
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
North American model: 87.5 - 108.0 MHz
(100-kHz step)
Other models: 87.5 - 108.0 MHz
(50-kHz step)
Antenna FM wire antenna
Antenna terminals 75 ohms unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
North American model: 530 - 1,710 kHz
(with the tuning interval set at
10 kHz)
531 - 1,710 kHz
(with the tuning interval set at
9 kHz)
European model: 531 - 1,602 kHz
(with the tuning interval set at
9 kHz)
Other models: 530 - 1,710 kHz
(with the tuning interval set at
10 kHz)
531 - 1,602 kHz
(with the tuning interval set at
9 kHz)
Antenna AM bar antenna, external antenna
terminal
Intermediate frequency 450 kHz
