CPD-101VS
– 2 –
DIAGNOSIS
Failure Power LED
+B Failure Blink Amber (On 0.5 sec, Off 0.5 sec)
H Stop or V Stop Failure
Blink Amber (On 1.5 sec, Off 0.5 sec)
(Included S-Cap Failure)
ABL Failure Blink Amber (On 0.5 sec, Off 1.5 sec)
Aging/Self-Test Blink Amber (On 0.5 sec, Off 0.5 sec) .... Blink Green (On 0.5 sec, Off 0.5 sec)
Out of Range On Green (OSD Indication)
TIMING SPECIFICATION
Power Saving Function
This display meets the power saving guidelines set by the International
E
NERGY
S
TAR Program. It is capable of reduced power consumption
when used with a computer equipped with Display Power Management
Signaling (DPMS). By sensing the absence of the sync signal coming
from the computer, it will reduce the power consumption as follows:
✔
CAUTION
The Power Saving function will automatically put the display into Deep Sleep mode if the
power switch is turned on without any video signal input. Once the horizontal and vertical
syncs are sensed, the display will automatically return to its Normal Operation mode.
u Power
indicator
Green
Green ˜
Orange
Orange
Off
Normal
Operation
Sleep
Deep Sleep
Power-off
Power
consumption
110 W (max)
15 W (max)
8 W (max)
0 W
Recovery
time
—
Approx. 3 sec.
Approx. 10 sec.
—
Mode
1
2
3
4
PRIMARY MODE PRIMARY
MODE AT PRODUCTION
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7 MODE 8 MODE 9
RESOLUTION 640 X 480 800 X 600 800 X 600 1024 X 768 1024 X 768 1280 X 1024 640 X 400 640 X 480 1152 X 864
CLOCK 36.000 MHZ 40.000 MHZ 49.500 MHZ 78.750 MHZ 94.500 MHZ 108.500 MHZ 25.175 MHZ 25.175 MHZ 80.000 MHZ
— HORIZONTAL —
H-FREQ 43.269 kHz 37.879 kHz 46.875 kHz 60.023 kHz 68.677 kHz 63.974 kHz 31.469 kHz 31.469 kHz 54.945 kHz
usec usec usec usec usec usec usec usec usec
H. TOTAL 23.111 26.4 21.333 16.66 14.561 15.631 31.778 31.778 18.2
H. BLK 5.333 6.4 5.172 3.657 3.725 3.834 6.356 6.356 3.8
H. FP 1.556 1 0.323 0.203 0.508 0.59 0.636 0.636 0.8
H. SYNC 1.556 3.2 1.616 1.219 1.016 1.18 3.813 3.813 1.4
H. BP 2.222 2.2 3.232 2.235 2.201 2.065 1.907 1.907 1.6
H. ACTIV 17.778 20 16.162 13.003 10.836 11.797 25.422 25.422 14.4
— VERTICAL —
V. FREQ(HZ) 85.008 Hz 60.317 Hz 75.000 Hz 75.029 Hz 84.997 Hz 60.013 Hz 70.086 Hz 59.940 Hz 59.984 Hz
lines lines lines lines lines lines lines lines lines
V. TOTAL 509 628 625 800 808 1066 449 525 916
V. BLK 29 28 25 32 40 42 49 45 52
V. FP 11111112106
V. SYNC 3 4 3 333225
V. BP 25 23 21 28 36 38 35 33 41
V. ACTIV 480 600 600 768 768 1024 400 480 864
— SYNC —
INT(G) NO NO NO NO NO NO NO NO NO
EXT(H/V)/POLARITY YES -/- YES +/+ YES +/+ NO +/+ YES +/+ YES +/+ YES -/+ YES -/- YES +/+
EXT(CS)/POLARITY NO NO NO NO NO NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT
98.4.27 VER.
