REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-101VS
7-8
(d)
IC902 8-759-537-27 IC CXA8071AP
IC904 8-759-165-80 IC PST600C-T
IC905 8-759-527-71 IC M24C08-BN6
<CHIP CONDUCTOR>
JR002 1-216-296-91 SHORT 0
JR003 1-216-295-91 SHORT 0
JR004 1-216-296-91 SHORT 0
JR005 1-216-296-91 SHORT 0
JR006 1-216-296-91 SHORT 0
JR007 1-216-296-91 SHORT 0
JR008 1-216-295-91 SHORT 0
JR009 1-216-296-91 SHORT 0
JR010 1-216-295-91 SHORT 0
JR011 1-216-296-91 SHORT 0
JR012 1-216-296-91 SHORT 0
JR013 1-216-296-91 SHORT 0
JR014 1-216-296-91 SHORT 0
JR015 1-216-296-91 SHORT 0
JR017 1-216-295-91 SHORT 0
JR018 1-216-295-91 SHORT 0
JR019 1-216-295-91 SHORT 0
JR020 1-216-295-91 SHORT 0
JR021 1-216-295-91 SHORT 0
<COIL>
L501 1-412-531-31 INDUCTOR 33UH
L502 1-412-531-31 INDUCTOR 33UH
L503 1-411-594-41 COIL, CHOKE 5mH
L506 1-412-550-11 INDUCTOR 1.2mH
L509 1-409-896-11 COIL, HORIZONTAL LINEARITY
L510 1-416-367-11 COIL, HORIZONTAL CENTER
L601 1-406-663-21 COIL, CHOKE 47UH
L602 ¡ 1-412-529-41 INDUCTOR 22UH
L603 1-412-537-31 INDUCTOR 100UH
L650 1-412-529-11 INDUCTOR 22UH
L651 1-410-645-31 INDUCTOR 100UH
L652 1-412-529-11 INDUCTOR 22UH
L653 1-412-529-11 INDUCTOR 22UH
L901 1-412-537-31 INDUCTOR 100UH
<FILTER>
LF601¡1-429-180-11 TRANSFORMER, LINE FILTER
<IC LINK>
PS600¡1-533-597-31LINK, IC (5A/90V AC, 60V DC)
PS601¡1-532-727-91LINK, IC (0.25A/150V)
<TRANSISTOR>
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q503 8-729-035-54 TRANSISTOR 2SJ449
Q504 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q505 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q506 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q507 8-729-041-29 TRANSISTOR BU2522AX-ON5008
Q508 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q509 8-729-043-28 TRANSISTOR PDTC124EK-115
Q510 8-729-042-42 TRANSISTOR 2SK2101-01MR-F141
Q511 8-729-042-34 TRANSISTOR IRFU110A
Q512 8-729-041-93 TRANSISTOR IRLI530GLF33
Q515 8-729-041-93 TRANSISTOR IRLI530GLF33
Q516 8-729-041-93 TRANSISTOR IRLI530GLF33
Q517 8-729-326-11 TRANSISTOR 2SC2611
Q518 8-729-140-50 TRANSISTOR 2SC3209LK
Q520 8-729-042-23 TRANSISTOR IRFI9620GSLF35
Q521 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q522 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q523 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q602 8-729-037-98 TRANSISTOR 2SK2194F08
Q603 8-729-043-33 TRANSISTOR PDTA124EK-115
Q604 8-729-043-28 TRANSISTOR PDTC124EK-115
Q605 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q606 8-729-041-93 TRANSISTOR IRLI530GLF33
Q607 8-729-209-15 TRANSISTOR 2SD2012
Q608 8-729-039-65 TRNSISTOR MX0541B-F
Q609 8-729-043-33 TRANSISTOR PDTA124EK-115
Q610 8-729-322-37 TRANSISTOR 2SJ175
Q611 8-729-043-28 TRANSISTOR PDTC124EK-115
Q654 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q670 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q671 8-729-200-17 TRANSISTOR 2SA1091-O
Q672 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q673 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q901 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q902 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q903 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q904 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q905 8-729-900-51 TRANSISTOR DTA114TK
<RESISTOR>
R401 1-249-383-11 CARBON 1.5 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
R403 1-214-798-21 METAL 1.8 1% 1/2W
R404 1-215-443-00 METAL 8.2K 1% 1/4W
R405 1-214-796-00 METAL 1.5 1% 1/2W
R406 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R407 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R408 1-216-089-91 RES,CHIP 47K 5% 1/10W
R409 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R410 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R411 1-216-691-11 METAL CHIP 47K 0.50%1/10W
R451 1-215-451-00 METAL 18K 1% 1/4W
R452 1-215-421-00 METAL 1K 1% 1/4W
