— 41 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
CPD-E200
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
C628 1-128-526-11 ELECT 100MF 20% 25V
C630 1-126-935-11 ELECT 470MF 20% 16V
C631 1-126-935-11 ELECT 470MF 20% 16V
C632 1-111-070-51 ELECT 0.0022F 20% 25V
C633 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C634 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C636 1-131-601-21 FILM 0.047MF 10% 250V
C637 1-107-888-11 ELECT 47MF 20% 25V
C638
!
1-113-912-11 CERAMIC 0.0047MF 20% 250V
C640 1-113-912-11 CERAMIC 0.0047MF 20% 250V
C641 1-128-526-11 ELECT 100MF 20% 16V
C643
!
1-113-912-11 CERAMIC 0.0047MF 20% 250V
C647 1-102-228-00 CERAMIC 470PF 10% 500V
C650 1-163-019-00 CERAMIC CHIP 0.0068MF 10% 50V
C660
!
1-113-912-11 CERAMIC 0.0047MF 20% 250V
C661 1-117-699-11 CERAMIC 0.001MF 99% 250V
C701 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C702 1-126-963-11 ELECT 4.7MF 20% 50V
C703 1-136-169-00 FILM 0.22MF 5% 50V
C704 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C705 1-130-495-00 FILM 0.1MF 5% 50V
C706 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C707 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C708 1-130-495-00 FILM 0.1MF 5% 50V
C709 1-126-941-11 ELECT 470MF 20% 25V
C710 1-126-941-11 ELECT 470MF 20% 25V
C711 1-130-495-00 FILM 0.1MF 5% 50V
C712 1-130-495-00 FILM 0.1MF 5% 50V
C713 1-126-927-11 ELECT 2200MF 20% 10V
C714 1-163-131-00 CERAMIC CHIP 390PF 5% 50V
C715 1-126-935-11 ELECT 470MF 20% 16V
C716 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C718 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C723 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C725 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C729 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C733 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C901 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C902 1-126-935-11 ELECT 470MF 20% 16V
C903 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C905 1-137-375-11 FILM 0.068MF 5% 50V
C906 1-136-177-00 FILM 1MF 5% 50V
C908 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C909 1-126-926-11 ELECT 1000MF 20% 10V
C910 1-130-495-00 FILM 0.1MF 5% 50V
C911 1-137-370-11 FILM 0.01MF 5% 50V
C912 1-126-933-11 ELECT 100MF 20% 16V
C913 1-130-495-00 FILM 0.1MF 5% 50V
C914 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C915 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C916 1-126-965-11 ELECT 22MF 20% 50V
C917 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C918 1-126-964-11 ELECT 10MF 20% 50V
C920 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C921 1-126-935-11 ELECT 470MF 20% 16V
C922 1-109-889-11 ELECT 1MF 20% 50V
C923 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C924 1-126-965-11 ELECT 22MF 20% 50V
C925 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C926 1-126-935-11 ELECT 470MF 20% 16V
C927 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C928 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C929 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C930 1-137-370-11 FILM 0.01MF 5% 50V
C931 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C935 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C936 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C937 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C938 1-126-934-11 ELECT 220MF 20% 16V
CONNECTOR
CN501 * 1-580-798-11 CONNECTOR PIN (DY) 6P
CN502 * 1-564-512-11 PLUG, CONNECTOR 9P
CN510 * 1-900-211-86 CONNECTOR ASSY
CN512 1-695-915-11 TAB (CONTACT)
CN513 1-695-915-11 TAB (CONTACT)
CN600
!
1-251-644-11 INLET, AC 3P (WITH NOISE FILTER)
CN601 * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN602 * 1-506-371-00 PIN, CONNECTOR 2P
CN604 1-695-915-11 TAB (CONTACT)
CN701 * 1-564-513-11 PLUG, CONNECTOR 10P
CN901 * 1-508-879-11 BASE POST
CN902 * 1-564-513-11 PLUG, CONNECTOR 10P
CN903 * 1-564-511-11 PLUG, CONNECTOR 8P
CN904 * 1-564-510-11 PLUG, CONNECTOR 7P
DIODE
D401 8-719-052-90 DIODE D1NL40-TA2
D402 8-719-928-85 DIODE HZS4.7NB2
D403 8-719-073-01 DIODE MA111-(K8).S0
D404 8-719-058-24 DIODE RB501V-40TE-17
D501 8-719-110-31 DIODE RD12ESB2
D502 8-719-981-00 DIODE ERC81-04
D504 8-719-110-49 DIODE RD18ESB2
D505 8-719-941-74 DIODE ERB91-02
D506 8-719-075-18 DIODE FMQ-G2FS
D507 8-719-109-85 DIODE RD5.1ESB2
D509 8-719-110-17 DIODE RD10ESB2
