4-075-164-11(1)
© 1999 Sony Corporation
Trinitron Color
Computer Display
Operating Instructions
Mode d’emploi
Manual de instrucciones
US
FR
ES
CPD-E500

Table of Contents

Other manuals for Sony CPD-E500 Marketing

Preview: Specifications
Specifications2 pages

Questions and Answers

  • A
    Angela ChenAug 21, 2025
    Why does my Sony Monitor picture flicker and how can I fix it?
    • A
      Andrew ReevesAug 21, 2025
      To resolve picture flickering, bouncing, oscillation, or scrambling on your Sony Monitor, try the following: * Isolate and eliminate any potential sources of electric or magnetic fields such as other monitors, laser printers, electric fans, fluorescent lighting, or televisions. * Move the monitor away from power lines or place a magnetic shield near the monitor. * Try plugging the monitor into a different AC outlet, preferably on a different circuit. * Try turning the monitor 90° to the left or right.
  • L
    Lynn MccarthySep 3, 2025
    How to correct curved edges on my Sony CPD-E500 Marketing Monitor image?
    • G
      gomezamandaSep 3, 2025
      Adjust the geometry settings on your Sony Monitor to correct the curved edges of the image.
  • S
    sarah03Sep 1, 2025
    How to remove wavy patterns (moire) from my Sony CPD-E500 Marketing screen?
    • S
      Scott RaySep 1, 2025
      To minimize moire patterns on your Sony Monitor, set 'CANCEL MOIRE' to ON and adjust the degree of moire cancellation until the moire is visible at a minimum.
  • A
    Angela ThompsonAug 30, 2025
    How do I fix ghosting on my Sony Monitor?
    • R
      Robin RodriguezAug 30, 2025
      To fix picture ghosting on your Sony Monitor, eliminate the use of video cable extensions and/or video switch boxes. Also, check that all plugs are firmly seated in their sockets.
  • O
    onelsonAug 29, 2025
    How to fix non-uniform color on my Sony CPD-E500 Marketing?
    • M
      Morgan PooleAug 29, 2025
      First, try degaussing the Sony Monitor. Equipment that generates a magnetic field, such as a speaker, placed near the monitor, or changing the direction the monitor faces, may cause color to lose uniformity. Also, try adjusting the landing.
  • M
    Maria RayAug 27, 2025
    How to resolve OUT OF SCAN RANGE message on my Sony CPD-E500 Marketing Monitor?
    • T
      Tina CarterAug 28, 2025
      Verify that the video frequency range is within the specifications for your Sony Monitor. If you replaced an old monitor, reconnect it and adjust the frequency range to Horizontal: 30 – 109 kHz and Vertical: 48 – 160 Hz.
  • R
    rodriguezgregoryAug 26, 2025
    Why is my Sony CPD-E500 Marketing picture fuzzy?
    • T
      Taylor DavisAug 27, 2025
      Try adjusting the brightness and contrast settings on your Sony Monitor. You can also try degaussing the monitor. If 'CANCEL MOIRE' is turned on, the picture may become fuzzy, so decrease the moire cancellation effect or turn 'CANCEL MOIRE' off.
  • B
    Brenda YoungAug 25, 2025
    What to do if my Sony CPD-E500 Marketing shows NO INPUT SIGNAL and the power indicator is orange?
    • J
      Jennifer EdwardsAug 25, 2025
      First, check that the video signal cable is properly connected to your Sony Monitor and all plugs are firmly seated in their sockets. Also, inspect the HD15 video input connector’s pins to ensure they are not bent or pushed in.
  • J
    johnstonderrickAug 23, 2025
    How to fix a Sony CPD-E500 Marketing if the power indicator is not lit?
    • T
      Tina LindseyAug 23, 2025
      First, ensure that the power cord is properly connected to the Sony Monitor. If it's still not working, check that the power switch is in the 'on' position.

Summary

Precautions

Warning on power connections

Important warnings about using the correct power cord for safe operation.

Installation

Identifying parts and controls

RESET button

Control button

Setup

Step 1: Connect your monitor to your computer

Instructions for connecting the monitor to different computer types.

Step 2: Connect the power cord

Procedure for connecting the monitor to a power source.

Step 3: Turn on the monitor and computer

Selecting the on-screen menu language (LANG)

Customizing Your Monitor

Using the control button

Adjusting the brightness and contrast

Adjusting the convergence (CONV)

Adjusting the quality of the picture (SCREEN)

Adjusting the color of the picture (COLOR)

Additional settings (OPTION)

Resetting the adjustments

Technical Features

Troubleshooting

If thin lines appear on your screen (damper wires)

On-screen messages

Explains common on-screen messages and their meanings.

Trouble symptoms and remedies

No picture

Troubleshooting steps for when the monitor displays no picture.

Picture flickers, bounces, oscillates, or is scrambled

Solutions for picture instability and scrambling.

Picture is fuzzy

Steps to improve picture fuzziness, including degaussing and moire settings.

Trouble symptoms and remedies (continued)

Picture is ghosting

Picture is not centered or sized properly

Self-diagnosis function

If the (power) indicator is green

Steps to perform self-diagnosis when the power indicator is green.

If the (power) indicator is flashing orange

Specifications

Sony CPD-E500 Marketing Specifications

General IconGeneral
Screen Size21 inches
Viewable Size19.8 inches
Dot Pitch0.24 mm
Vertical Refresh Rate50-160 Hz
Bandwidth300 MHz
Input SignalAnalog RGB
Aspect Ratio4:3
Display TypeCRT
Refresh RateUp to 160 Hz
Horizontal Refresh Rate30 kHz - 121 kHz
