43
CX-LEM550
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C227 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C232 1-126-963-11 ELECT 4.7uF 20% 50V
C233 1-130-492-11 MYLAR 0.056uF 5% 50V
C234 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C236 1-126-964-11 ELECT 10uF 20% 50V
C237 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C301 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C302 1-126-923-91 ELECT 220uF 20% 10V
C305 1-126-923-91 ELECT 220uF 20% 10V
C309 1-126-767-11 ELECT 1000uF 20% 16V
C312 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C313 1-126-933-11 ELECT 100uF 20% 16V
C314 1-136-967-11 FILM 0.012uF 5% 100V
C319 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C320 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C324 1-126-934-11 ELECT 220uF 20% 16V
C326 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C327 1-126-947-11 ELECT 47uF 20% 35V
C328 1-126-933-11 ELECT 100uF 20% 16V
C329 1-126-933-11 ELECT 100uF 20% 16V
C330 1-126-923-91 ELECT 220uF 20% 10V
C331 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C332 1-126-923-91 ELECT 220uF 20% 10V
C335 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C336 1-126-965-91 ELECT 22uF 20% 50V
C337 1-126-965-91 ELECT 22uF 20% 50V
C338 1-104-658-91 ELECT 100uF 20% 10V
C339 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C340 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C341 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C345 1-126-964-11 ELECT 10uF 20% 50V
C346 1-126-768-11 ELECT 2200uF 20% 16V
C347 1-165-621-91 CERAMIC CHIP 0.1uF 50V
C350 1-126-964-11 ELECT 10uF 20% 50V
C351 1-126-947-11 ELECT 47uF 20% 35V
C352 1-128-550-11 ELECT 2200uF 20% 50V
C353 1-128-550-11 ELECT 2200uF 20% 50V
C354 1-126-961-11 ELECT 2.2uF 20% 50V
C355 1-130-485-00 MYLAR 0.015uF 5% 50V
C356 1-130-481-00 MYLAR 0.0068uF 5% 50V
C357 1-130-481-00 MYLAR 0.0068uF 5% 50V
C358 1-130-486-00 MYLAR 0.018uF 5% 50V
C360 1-126-964-11 ELECT 10uF 20% 50V
C361 1-126-947-11 ELECT 47uF 20% 35V
C362 1-126-964-11 ELECT 10uF 20% 50V
C363 1-126-963-11 ELECT 4.7uF 20% 50V
C364 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C384 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C390 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C391 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C393 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C394 1-164-159-21 CERAMIC 0.1uF 50V
C395 1-126-933-11 ELECT 100uF 20% 16V
C396 1-126-923-91 ELECT 220uF 20% 10V
C399 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
* CN301 1-564-709-11 PIN, CONNECTOR (SMALL TYPE) 7P
* CN302 1-784-785-11 CONNECTOR, FFC 24P
CN303 1-784-777-11 CONNECTOR, FFC 16P
CN305 1-784-835-21 CONNECTOR, FFC (LIF (NON-ZIF)) 27P
CN501B 1-564-507-11 PLUG, CONNECTOR 4P
CNB307 1-564-507-11 PLUG, CONNECTOR 4P
* CNB308 1-564-512-11 PLUG, CONNECTOR 9P
CNB903 not supplied
CNB903A not supplied
CNB903B not supplied
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-109-72 DIODE RD3.9ESB2
D304 8-719-109-66 DIODE RD3.3ESB2
D305 8-719-056-78 DIODE UDZ-TE-17-4.3B
D306 8-719-056-78 DIODE UDZ-TE-17-4.3B
D307 8-719-991-33 DIODE 1SS133T-77
D308 8-719-991-33 DIODE 1SS133T-77
D309 8-719-991-33 DIODE 1SS133T-77
D310 8-719-109-72 DIODE RD3.9ESB2
D311 8-719-109-66 DIODE RD3.3ESB2
D312 8-719-063-79 DIODE 1N4002B
D313 8-719-063-79 DIODE 1N4002B
D317 8-719-991-33 DIODE 1SS133T-77
D318 8-719-982-27 DIODE MTZJ-33C
D319 8-719-991-33 DIODE 1SS133T-77
D320 8-719-063-79 DIODE 1N4002B
D386 8-719-991-33 DIODE 1SS133T-77
D387 8-719-991-33 DIODE 1SS133T-77
D388 8-719-991-33 DIODE 1SS133T-77
D389 8-719-991-33 DIODE 1SS133T-77
D390 8-719-109-85 DIODE RD5.1ESB2
D392 8-719-109-66 DIODE RD3.3ESB2
D393 8-719-991-33 DIODE 1SS133T-77
D396 8-719-991-33 DIODE 1SS133T-77
< FERRITE BEAD >
FB301 1-410-396-41 FERRITE 0.45uH
FB302 1-410-396-41 FERRITE 0.45uH
< IC >
IC302 6-702-895-01 IC BD3881FV
< JACK >
J302 1-536-708-81 TERMINAL BOARD, PUSH (4P)
(SPEAKER IMPEDANCE USE 6-16Ω)
* J303 1-750-178-31 JACK, PIN 2P (MD)
< SHORT >
JR101 1-216-864-11 SHORT CHIP 0
JR201 1-216-864-11 SHORT CHIP 0
JR302 1-216-296-11 SHORT CHIP 0
JR303 1-216-296-11 SHORT CHIP 0
MAIN
To Next Page
