Sony Cyber-shot DSC-N2 Service Manual

1-4E
DSC-N2_L2
1-4. PRECAUTION ON REPLACING THE SY-165 BOARD
VIDEO OUT Default Data Check
When you replace to the repairing board, the written data of repairing board also might be changed to original setteing because of broadcast
system (NTSC/PAL).
When the data has changed because of board replaceing etc, check the default data of VIDEO OUT if destination code is right. If not, rewrite
to the right value.
VIDEO OUT Default Data
Writing Method:
1) Select page: 00, address: 01 and set data: 01.
2) Select page: 4F, address: 89, and set data: 00 (NTSC) or data: 01 (PAL).
3) Select page: 4F, address: A2, and set data: 00 (NTSC) or data: 01 (PAL).
4) Select page: 40, address: 38, and set data: 00.
5) Click [Save] on the SEUS screen.
6) Select page: 80, address: 34, and check that the data is “00”.
7) Select page: 80, address: 30, and check that the data is “00”.
8) Select page: 00, address: 01, and set data: 00.
Initial Language Data Check
If the SY-165 board was replaced, initial language setting may be changed. Accordingly, change the following data so as to set same initial
language as that of the set distributing in each region.
Initial language: Language displayed at the next starting if the setting of Setup menu was reset.
It is different from the language setting selectable with the menu.
Initial Language Data
Page Address Data Language GP1 GP2 GP3 GP4
4F 88
00 English zzz
01 Japanese z
04 Spanish zz
08 Simplified Chinese z
0B Russian z
0D Korean z
Note: GP1 is fixed to Japanese.
GP2 is fixed to English.
GP3 is either English, Spanish or Russian.
GP4 is either English, Spanish, Simplified Chinese or Korean.
Writing Method:
1) Select page: 00, address: 01 and set data: 01.
2) Select page: 4F, address: 88, and set the Initial Language Data.
3) Select page: 40, address: 38, and set data: 00.
4) Click
[Save] on the SEUS screen.
5) Select page: 80, address: 34, and check that the data is “00”.
6) Select page: 80, address: 30, and check that the data is “00”.
7) Select page: 00, address: 01, and set data: 00.
8) Turn off the camera.
9) Turn on the camera. Execute “Initialize” of Setup screen.
10) Check the language displayed when the camera starts.
Address
00 01894F
Page
Data
NTSC PAL
00 01A24F
