— 21 —
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Abbreviation
AUS : Australian model
CH : Chinese model
CND : Canadian model
EE : East European model
FR : French model
G : German model
HK : Hong Kong model
KR : Korea model
A-3323-357-A MAIN BOARD, COMPLETE (EXCEPT FR)
*********************
A-3323-358-A MAIN BOARD, COMPLETE (FR)
*********************
1-791-471-11 WIRE
4-222-766-01 TERMINAL (+), BATTERY
< CAPACITOR >
C101 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C102 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C103 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C151 1-115-156-11 CERAMIC CHIP 1uF 10V
C154 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C155 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C201 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C202 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C203 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C251 1-115-156-11 CERAMIC CHIP 1uF 10V
C254 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C255 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C301 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C351 1-115-156-11 CERAMIC CHIP 1uF 10V
C352 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C353 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C354 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C356 1-127-569-91 TANTAL. CHIP 100uF 20% 4V
C357 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C404 1-125-822-11 TANTALUM 10uF 20.00% 10V
C405 1-115-156-11 CERAMIC CHIP 1uF 10V
C406 1-110-569-11 TANTAL. CHIP 47uF 20.00% 6.3V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C409 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C410 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C411 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-104-752-11 TANTAL. CHIP 33uF 20.00% 6.3V
C418 1-128-705-11 ELECT 0PF 0V
C420 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C421 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C422 1-125-838-91 CERAMIC CHIP 2.2uF 10% 6.3V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C425 1-115-156-11 CERAMIC CHIP 1uF 10V
C426 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C427 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C428 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C431 1-104-752-11 TANTAL. CHIP 33uF 20.00% 6.3V
C432 1-104-752-11 TANTAL. CHIP 33uF 20.00% 6.3V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C435 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C442 1-115-156-11 CERAMIC CHIP 1uF 10V
C451 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C453 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C461 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C462 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
C501 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C602 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C603 1-107-826-91 CERAMIC CHIP 0.1uF 10.00% 16V
C604 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C607 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C609 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C611 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C612 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C613 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C614 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C615 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C620 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C621 1-163-189-00 CERAMIC CHIP 220PF 5.00% 50V
C622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C623 1-115-156-11 CERAMIC CHIP 1uF 10V
C624 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C625 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C626 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V
C627 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C629 1-164-156-11 CERAMIC CHIP 0.1uF 25V
MAIN
