Sony D-E770 - Page 16

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 24 —
R645 1-216-845-11 METAL CHIP 100K 5% 1/16W
R646 1-216-845-11 METAL CHIP 100K 5% 1/16W
R801 1-216-845-11 METAL CHIP 100K 5% 1/16W
R802 1-216-845-11 METAL CHIP 100K 5% 1/16W
R803 1-216-843-11 METAL CHIP 68K 5% 1/16W
R805 1-216-821-11 METAL CHIP 1K 5% 1/16W
R808 1-216-864-11 METAL CHIP 0 5% 1/16W
R809 1-216-845-11 METAL CHIP 100K 5% 1/16W
R810 1-216-864-11 METAL CHIP 0 5% 1/16W
R811 1-216-864-11 METAL CHIP 0 5% 1/16W
R812 1-216-864-11 METAL CHIP 0 5% 1/16W
R813 1-216-847-11 METAL CHIP 150K 5% 1/16W
(FR)
R813 1-216-839-11 METAL CHIP 33K 5% 1/16W
(EXCEPT FR)
R814 1-216-845-11 METAL CHIP 100K 5% 1/16W
R816 1-216-864-11 METAL CHIP 0 5% 1/16W
R819 1-216-843-11 METAL CHIP 68K 5% 1/16W
(FR)
R819 1-216-847-11 METAL CHIP 150K 5% 1/16W
(EXCEPT FR)
R820 1-216-864-11 METAL CHIP 0 5% 1/16W
R821 1-216-864-11 METAL CHIP 0 5% 1/16W
R823 1-216-833-91 RES-CHIP 10K 5% 1/16W
R824 1-216-833-91 RES-CHIP 10K 5% 1/16W
R825 1-216-864-11 METAL CHIP 0 5% 1/16W
R826 1-216-845-11 METAL CHIP 100K 5% 1/16W
R831 1-216-857-11 METAL CHIP 1M 5% 1/16W
R832 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R833 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R841 1-216-857-11 METAL CHIP 1M 5% 1/16W
R842 1-216-833-91 RES-CHIP 10K 5% 1/16W
R845 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R846 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
< SWITCH >
S801 1-692-366-31 SWITCH, PUSH (1 KEY) (OPEN)
S802 1-762-078-11 SWITCH, SLIDE (AVLS)
S803 1-762-078-11 SWITCH, SLIDE (HOLD)
S804 1-762-078-11 SWITCH, SLIDE (G-PROTECTION)
S805 1-572-499-21 SWITCH, TACTIL (VOLUME +)
S806 1-572-499-21 SWITCH, TACTIL (VOLUME −)
< VARISTOR >
VDR101 1-801-862-11 VARISTOR, CHIP
VDR111 1-801-862-11 VARISTOR, CHIP
VDR201 1-801-862-11 VARISTOR, CHIP
VDR211 1-801-862-11 VARISTOR, CHIP
VDR311 1-801-862-11 VARISTOR, CHIP
VDR312 1-801-862-11 VARISTOR, CHIP
VDR313 1-801-862-11 VARISTOR, CHIP
< VIBRATOR >
X601 1-767-605-11 VIBRATOR, LITHIUM TANTALATE 16.9MHz
************************************************************
MISCELLANEOUS
**************
8 1-418-565-11 SWITCH UNIT
0113 X-4952-506-1 OPTICAL PICK-UP (DAX-23E)
M901 A-3328-627-A MOTOR ASSY, SLED (WITH GEAR)
M902 A-3328-759-A MOTOR ASSY, TURN TABLE (SPINDLE)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-418-670-11 REMOTE CONTROL UNIT (RM-CD6)(EJ715:US)
1-418-730-11 REMOTE CONTROL UNIT (RM-CD11L)
(EXCEPT EJ711/EJ715:US)
0 1-467-007-21 ADAPTOR, AC (AC-E455) (EJ715:AUS)
0 1-467-009-21 ADAPTOR, AC (AC-E455D)
(EJ711/EJ715:US,CND)
0 1-467-009-21 ADAPTOR, AC (AC-E455) (EJ715:US,CND)
0 1-467-195-11 ADAPTOR, AC (AC-E455A) (EJ711)
0 1-467-550-11 ADAPTOR, AC (AC-E455A) (E770/EJ715:E33)
0 1-473-115-11 ADAPTOR, AC (AC-E455D) (EJ715:UK)
0 1-473-116-35 ADAPTOR, AC (AC-E455D)
(EJ715:AEP,E13,EE,G,FR)
0 1-475-622-11 ADAPTOR, AC (AC-E455) (EJ715:CH)
0 1-475-623-11 ADAPTOR, AC (AC-E455) (EJ715:HK)
0 1-569-007-11 ADAPTOR, CONVERSION 2P (E770/EJ715:E33)
1-756-035-11 BATTERY PACK (NC-WMAA)
(E770/EJ715:AUS,CH,E13,E33,HK,KR)
1-756-035-21 BATTERY PACK (NC-WMAA)
(EJ715:AEP,UK,EE,G,FR)
1-756-035-31 BATTERY PACK (NC-WMAA) (EJ715:US,CND)
3-046-316-01 CASE, CARRYING (EJ711/EJ715:US)
3-046-317-01 POUCH, CARRYING
(E770/EJ715:AUS,CH,E13,E33,HK,KR)
3-046-668-11 MANUAL, INSTRUCTION (ENGLISH)
(EJ711/EJ715:US)
3-868-101-11 MANUAL, INSTRUCTION (SPANISH)
(E770/EJ715:AEP,E33)
3-868-101-21 MANUAL, INSTRUCTION (ENGLISH)
(E770/EJ715:CND,AEP,UK,AUS,E33,EE,FR)
3-868-101-31 MANUAL, INSTRUCTION (FRENCH)
(E770/EJ715:CND,AEP,FR)
3-868-101-41 MANUAL, INSTRUCTION (DUTCH)
(EJ715:AEP,EE)
3-868-101-51 MANUAL, INSTRUCTION (SWEDISH)
(EJ715:AEP)
3-868-101-61 MANUAL, INSTRUCTION (PORTUGUESE)
(EJ715:AEP)
3-868-101-71 MANUAL, INSTRUCTION (GERMAN)
(EJ715:AEP,G)
3-868-101-81 MANUAL, INSTRUCTION (ITALIAN)(EJ715:AEP)
3-868-101-91 MANUAL, INSTRUCTION (FINNISH)(EJ715:AEP)
3-868-102-11 MANUAL, INSTRUCTION (CHINESE)
(EJ715:E13,HK)
3-868-102-21 MANUAL, INSTRUCTION (ENGLISH)
(EJ715:CH,E13,HK)
3-868-102-31 MANUAL, INSTRUCTION (CHINESE)(EJ715:CH)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN
