— 8 —
Pin No.
69
70
71
72
73
74
75
76
77
78
79
80
I/O
—
—
—
—
—
I
I
O
O
I
I
O
Pin Name
V3
V2
V1
C1
C0
STOP
TEST
SCSY_0
XBACKLIGHT_O
RESET_I
XIN
XOUT
Description
Charge pump C
Charge pump C
0.5Vcpu input
Charge pump C
Charge pump C
STOP mode release signal input
68k pull-down
External BB control
LCD backlight control
MCU reset input
Crystal input from CXD3027R
No connection
