Sony D-NF430 - Page 32

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
32
D-NF430/NF431
R433 1-218-990-11 SHORT CHIP 0
R434 1-218-990-11 SHORT CHIP 0
R435 1-218-990-11 SHORT CHIP 0
R436 1-218-990-11 SHORT CHIP 0
R437 1-218-990-11 SHORT CHIP 0
R438 1-218-990-11 SHORT CHIP 0
R439 1-218-973-11 RES-CHIP 47K 5% 1/16W
R442 1-218-977-11 RES-CHIP 100K 5% 1/16W
R452 1-218-977-11 RES-CHIP 100K 5% 1/16W
R454 1-218-990-11 SHORT CHIP 0
R455 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R457 1-216-864-11 SHORT CHIP 0
R458 1-216-864-11 SHORT CHIP 0
R459 1-218-990-11 SHORT CHIP 0
R460 1-218-990-11 SHORT CHIP 0
R461 1-216-864-11 SHORT CHIP 0
R462 1-216-864-11 SHORT CHIP 0
R463 1-216-295-00 SHORT CHIP 0
R464 1-218-990-11 SHORT CHIP 0
R465 1-218-990-11 SHORT CHIP 0
R467 1-218-945-11 RES-CHIP 220 5% 1/16W
R468 1-218-981-11 RES-CHIP 220K 5% 1/16W
R470 1-218-973-11 RES-CHIP 47K 5% 1/16W
R473 1-216-864-11 SHORT CHIP 0
R474 1-216-296-11 SHORT CHIP 0
R480 1-218-977-11 RES-CHIP 100K 5% 1/16W
R482 1-218-969-11 RES-CHIP 22K 5% 1/16W
R601 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R602 1-218-990-11 SHORT CHIP 0
R604 1-218-989-11 RES-CHIP 1M 5% 1/16W
R606 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R607 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R609 1-218-969-11 RES-CHIP 22K 5% 1/16W
R610 1-218-977-11 RES-CHIP 100K 5% 1/16W
R611 1-218-973-11 RES-CHIP 47K 5% 1/16W
R612 1-218-977-11 RES-CHIP 100K 5% 1/16W
R613 1-218-981-11 RES-CHIP 220K 5% 1/16W
R614 1-218-981-11 RES-CHIP 220K 5% 1/16W
R615 1-218-969-11 RES-CHIP 22K 5% 1/16W
R616 1-218-973-11 RES-CHIP 47K 5% 1/16W
R617 1-218-969-11 RES-CHIP 22K 5% 1/16W
R618 1-216-864-11 SHORT CHIP 0
R619 1-218-973-11 RES-CHIP 47K 5% 1/16W
R620 1-218-977-11 RES-CHIP 100K 5% 1/16W
R623 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R630 1-216-295-00 SHORT CHIP 0
R631 1-218-929-11 RES-CHIP 10 5% 1/16W
R634 1-218-990-11 SHORT CHIP 0
R644 1-218-990-11 SHORT CHIP 0
R647 1-218-989-11 RES-CHIP 1M 5% 1/16W
R681 1-218-985-11 RES-CHIP 470K 5% 1/16W
R682 1-218-985-11 RES-CHIP 470K 5% 1/16W
R683 1-218-977-11 RES-CHIP 100K 5% 1/16W
R684 1-218-985-11 RES-CHIP 470K 5% 1/16W
R685 1-218-977-11 RES-CHIP 100K 5% 1/16W
R686 1-218-985-11 RES-CHIP 470K 5% 1/16W
R801 1-216-295-00 SHORT CHIP 0
R803 1-218-977-11 RES-CHIP 100K 5% 1/16W
R805 1-216-295-00 SHORT CHIP 0
R809 1-218-990-11 SHORT CHIP 0
R810 1-218-990-11 SHORT CHIP 0
R811 1-218-989-11 RES-CHIP 1M 5% 1/16W
R812 1-218-953-11 RES-CHIP 1K 5% 1/16W
R813 1-218-990-11 SHORT CHIP 0
R815 1-218-990-11 SHORT CHIP 0
R816 1-218-990-11 SHORT CHIP 0
R824 1-218-990-11 SHORT CHIP 0
R825 1-218-990-11 SHORT CHIP 0
R826 1-218-990-11 SHORT CHIP 0
R854 1-216-295-00 SHORT CHIP 0
R855 1-218-990-11 SHORT CHIP 0
R856 1-218-933-11 RES-CHIP 22 5% 1/16W
R858 1-218-990-11 SHORT CHIP 0
R859 1-218-990-11 SHORT CHIP 0
R860 1-218-933-11 RES-CHIP 22 5% 1/16W
R865 1-218-990-11 SHORT CHIP 0
R866 1-218-933-11 RES-CHIP 22 5% 1/16W
R867 1-218-933-11 RES-CHIP 22 5% 1/16W
R869 1-216-864-11 SHORT CHIP 0
R871 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R872 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R873 1-218-953-11 RES-CHIP 1K 5% 1/16W
R874 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R887 1-218-977-11 RES-CHIP 100K 5% 1/16W
R891 1-216-864-11 SHORT CHIP 0
R893 1-218-977-11 RES-CHIP 100K 5% 1/16W
R894 1-218-977-11 RES-CHIP 100K 5% 1/16W
R897 1-218-953-11 RES-CHIP 1K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB601 1-233-969-11 RES, NETWORK (CHIP TYPE) 22K
< SWITCH >
S801 1-762-805-41 SWITCH, PUSH (1 KEY) (OPEN)
S802 1-572-922-11 SWITCH, SLIDE (HOLD)
< COIL/TRANSFORMER >
T101 1-456-985-11 COIL, AM OSC
T102 1-443-490-11 TRANSFORMER, IF (AM IFT)
T103 1-443-599-11 TRANSFORMER, DC-DC CONVERTER
< THERMISTOR >
TH401 1-805-719-11 THERMISTOR, POSITIVE
< VARISTOR >
VDR401 1-801-864-21 VARISTOR, CHIP (1608)
< VIBRATOR >
X601 1-813-421-21 VIBRATOR, CERAMIC (22.496MHz)
************************************************************
MAIN
