Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 50 —
R545 1-216-849-11 METAL CHIP 220K 5% 1/16W
R546 1-218-879-11 METAL GLAZE 22K 0.50% 1/16W
R547 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R548 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R549 1-216-833-11 METAL CHIP 10K 5% 1/16W
R550 1-216-864-11 METAL CHIP 0 5% 1/16W
R552 1-216-864-11 METAL CHIP 0 5% 1/16W
R557 1-216-864-11 METAL CHIP 0 5% 1/16W
R558 1-218-852-11 METAL GLAZE 1.6K 0.50% 1/16W
R559 1-218-903-11 METAL GLAZE 220K 0.50% 1/16W
R567 1-218-871-11 METAL GLAZE 10K 0.50% 1/16W
R569 1-216-841-11 METAL CHIP 47K 5% 1/16W
R571 1-216-864-11 METAL CHIP 0 5% 1/16W
R573 1-216-864-11 METAL CHIP 0 5% 1/16W
R574 1-216-846-11 METAL CHIP 120K 5% 1/16W
R575 1-216-846-11 METAL CHIP 120K 5% 1/16W
R576 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R577 1-218-885-11 METAL GLAZE 39K 0.50% 1/16W
R578 1-216-845-11 METAL CHIP 100K 5% 1/16W
R603 1-216-833-11 METAL CHIP 10K 5% 1/16W
R604 1-216-833-11 METAL CHIP 10K 5% 1/16W
R611 1-216-864-11 METAL CHIP 0 5% 1/16W
(T405)
R613 1-216-864-11 METAL CHIP 0 5% 1/16W
(T101)
R614 1-216-864-11 METAL CHIP 0 5% 1/16W
(T101,T405)
R615 1-216-864-11 METAL CHIP 0 5% 1/16W
(T101,T405)
R802 1-216-833-11 METAL CHIP 10K 5% 1/16W
R803 1-216-821-11 METAL CHIP 1K 5% 1/16W
R804 1-216-854-11 METAL CHIP 560K 5% 1/16W
R805 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R806 1-216-857-11 METAL CHIP 1M 5% 1/16W
R807 1-216-857-11 METAL CHIP 1M 5% 1/16W
R808 1-216-821-11 METAL CHIP 1K 5% 1/16W
R809 1-216-857-11 METAL CHIP 1M 5% 1/16W
R810 1-216-857-11 METAL CHIP 1M 5% 1/16W
R812 1-216-864-11 METAL CHIP 0 5% 1/16W
R822 1-218-883-11 METAL GLAZE 33K 0.50% 1/16W
R823 1-216-853-11 METAL CHIP 470K 5% 1/16W
R828 1-218-903-11 METAL GLAZE 220K 0.50% 1/16W
(T405)
R829 1-218-901-11 METAL GLAZE 180K 0.50% 1/16W
(T405)
R830 1-218-907-11 METAL GLAZE 330K 0.50% 1/16W
(T401,T405)
R832 1-216-833-11 METAL CHIP 10K 5% 1/16W
R835 1-216-821-11 METAL CHIP 1K 5% 1/16W
R836 1-218-895-11 METAL GLAZE 100K 0.50% 1/16W
R837 1-218-895-11 METAL GLAZE 100K 0.50% 1/16W
R838 1-216-857-11 METAL CHIP 1M 5% 1/16W
R841 1-216-821-11 METAL CHIP 1K 5% 1/16W
R842 1-216-821-11 METAL CHIP 1K 5% 1/16W
R843 1-216-821-11 METAL CHIP 1K 5% 1/16W
R844 1-216-833-11 METAL CHIP 10K 5% 1/16W
R847 1-216-295-91 CONDUCTOR, CHIP (2012)
R848 1-216-857-11 METAL CHIP 1M 5% 1/16W
R849 1-216-821-11 METAL CHIP 1K 5% 1/16W
R850 1-216-821-11 METAL CHIP 1K 5% 1/16W
R851 1-216-821-11 METAL CHIP 1K 5% 1/16W
R852 1-216-864-11 METAL CHIP 0 5% 1/16W
R853 1-216-864-11 METAL CHIP 0 5% 1/16W
R854 1-216-864-11 METAL CHIP 0 5% 1/16W
R855 1-216-821-11 METAL CHIP 1K 5% 1/16W
R856 1-216-821-11 METAL CHIP 1K 5% 1/16W
R857 1-216-821-11 METAL CHIP 1K 5% 1/16W
R858 1-216-821-11 METAL CHIP 1K 5% 1/16W
R859 1-216-864-11 METAL CHIP 0 5% 1/16W
R860 1-216-864-11 METAL CHIP 0 5% 1/16W
R861 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
R862 1-216-864-11 METAL CHIP 0 5% 1/16W
R863 1-216-864-11 METAL CHIP 0 5% 1/16W
R864 1-216-864-11 METAL CHIP 0 5% 1/16W
R865 1-216-864-11 METAL CHIP 0 5% 1/16W
R866 1-216-864-11 METAL CHIP 0 5% 1/16W
R867 1-216-864-11 METAL CHIP 0 5% 1/16W
R868 1-216-821-11 METAL CHIP 1K 5% 1/16W
R870 1-216-864-11 METAL CHIP 0 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-223-382-11 RES, VAR, CARBON 10K/10K
RV401 1-241-395-11 RES, ADJ, METAL GLAZE 10K
RV501 1-241-395-11 RES, ADJ, METAL GLAZE 10K
RV502 1-223-587-11 RES, ADJ, CARBON 22K
RV503 1-223-587-11 RES, ADJ, CARBON 22K
< SWITCH >
S301 1-762-078-11 SWITCH, SLIDE (AVLS)
S801 1-570-953-11 SWITCH, PUSH (1 KEY) (OPEN)
S802 1-762-455-21 SWITCH, PUSH (1 KEY) (BATT)
S803 1-762-078-11 SWITCH, SLIDE (RESUME)
S804 1-762-078-11 SWITCH, SLIDE (HOLD)
< TRANSFORMER >
T401 1-429-850-11 TRANSFORMER, DC-DC CONVERTER
T402 1-429-851-11 TRANSFORMER, DC-DC CONVERTER
< VIBRATOR >
X301 1-760-023-21 VIBRATOR, CRYSTAL 16.9MHz
X801 1-579-063-21 VIBRATOR, CERAMIC 4.19MHz
************************************************************
A-3306-405-A ESP BOARD, COMPLETE (T401)
********************
A-3306-394-A ESP BOARD, COMPLETE (T405)
********************
< CAPACITOR >
C601 1-164-346-11 CERAMIC CHIP 1uF 16V
(T401,T405)
C602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(T401,T405)
C603 1-164-346-11 CERAMIC CHIP 1uF 16V
(T401,T405)
< CONNECTOR >
CN602 1-778-710-41 CONNECTOR, BOARD TO BOARD 24P
(T401,T405)
CD ESP
