Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 51 —
< FERRITE BEAD >
FB601 1-216-295-91 CONDUCTOR, CHIP (2012) (T401,T405)
< IC >
IC601 8-759-445-16 IC SM5859AF (T401)
IC601 8-759-479-88 IC SM5858BF (T405)
IC602 8-759-349-44 IC MB81V4400C-60PFTN (T401,T405)
< JUMPER RESISTER >
JC602 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
JC603 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
JC604 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
< RESISTOR >
R602 1-216-833-11 METAL CHIP 10K 5% 1/16W
(T401,T405)
R605 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
R606 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
R607 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
R608 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
R609 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
R610 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401,T405)
R612 1-216-821-11 METAL CHIP 1K 5% 1/16W
(T405)
************************************************************
A-3293-386-A TUNER BOARD, COMPLETE
(AEP,IT,UK/T101:EA)
**********************
A-3293-385-A TUNER BOARD, COMPLETE
( E13,E33,E92,AUS,CN/T401,T405:US,CND)
**********************
A-3293-384-A TUNER BOARD, COMPLETE (T405:JEW)
***********************
1-694-264-11 CONDUCTIVE BOARD, CONNECTION
4-989-982-01 HOLDER (LCD)
< CAPACITOR >
C6 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C7 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C8 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C9 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C10 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C11 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C12 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C13 1-162-911-11 CERAMIC CHIP 6PF 0.5PF 50V
C14 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C15 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C16 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C17 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C18 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
(T101,T401/T405:EXCEPT JEW)
C19 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C20 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C21 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C22 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C23 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C25 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C26 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C27 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C28 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C29 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C30 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C31 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C32 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C33 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C34 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C35 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C36 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C37 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C38 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C39 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C40 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C41 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C42 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C43 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C44 1-104-912-11 TANTAL. CHIP 3.3uF 20% 16V
C45 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C46 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C47 1-115-156-11 CERAMIC CHIP 1uF 10V
C48 1-115-156-11 CERAMIC CHIP 1uF 10V
C49 1-104-912-11 TANTAL. CHIP 3.3uF 20% 16V
C50 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C51 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C52 1-104-912-11 TANTAL. CHIP 3.3uF 20% 16V
C53 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C54 1-164-345-11 CERAMIC CHIP 0.082uF 10% 25V
C55 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C56 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C57 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C58 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C59 1-115-156-11 CERAMIC CHIP 1uF 10V
C60 1-115-156-11 CERAMIC CHIP 1uF 10V
C61 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C62 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C63 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C64 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C65 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C66 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C67 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C68 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C69 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C70 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C72 1-115-156-11 CERAMIC CHIP 1uF 10V
C73 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C74 1-104-912-11 TANTAL. CHIP 3.3uF 20% 16V
C75 1-115-156-11 CERAMIC CHIP 1uF 10V
C80 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C81 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C82 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C83 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C84 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
ESP TUNER
