Sony D-T101 - Page 32

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 53 —
Q38 8-729-429-71 TRANSISTOR XN4314-TX
Q39 8-729-420-16 TRANSISTOR XN1214-TX
Q40 8-729-402-93 TRANSISTOR UN5214-TX
Q41 8-729-429-71 TRANSISTOR XN4314-TX (T405:JEW)
Q42 8-729-402-93 TRANSISTOR UN5214-TX
Q43 8-729-420-16 TRANSISTOR XN1214-TX
Q44 8-729-030-46 TRANSISTOR XP4314-TX
< RESISTOR >
R1 1-216-843-11 METAL CHIP 68K 5% 1/16W
R2 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4 1-216-845-11 METAL CHIP 100K 5% 1/16W
R5 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R6 1-216-839-11 METAL CHIP 33K 5% 1/16W
R8 1-216-853-11 METAL CHIP 470K 5% 1/16W
R9 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R10 1-216-809-11 METAL CHIP 100 5% 1/16W
R11 1-216-815-11 METAL CHIP 330 5% 1/16W
R12 1-216-843-11 METAL CHIP 68K 5% 1/16W
R13 1-216-821-11 METAL CHIP 1K 5% 1/16W
R14 1-216-813-11 METAL CHIP 220 5% 1/16W
R16 1-216-821-11 METAL CHIP 1K 5% 1/16W
R18 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R19 1-216-845-11 METAL CHIP 100K 5% 1/16W
R20 1-216-833-11 METAL CHIP 10K 5% 1/16W
R21 1-216-857-11 METAL CHIP 1M 5% 1/16W
R22 1-216-853-11 METAL CHIP 470K 5% 1/16W
R23 1-216-833-11 METAL CHIP 10K 5% 1/16W
R24 1-216-857-11 METAL CHIP 1M 5% 1/16W
R25 1-216-837-11 METAL CHIP 22K 5% 1/16W
R26 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R27 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R28 1-216-833-11 METAL CHIP 10K 5% 1/16W
R29 1-216-837-11 METAL CHIP 22K 5% 1/16W
R30 1-216-833-11 METAL CHIP 10K 5% 1/16W
R31 1-216-833-11 METAL CHIP 10K 5% 1/16W
R32 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R34 1-216-817-11 METAL CHIP 470 5% 1/16W
R35 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R36 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R37 1-216-821-11 METAL CHIP 1K 5% 1/16W
R38 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R39 1-216-833-11 METAL CHIP 10K 5% 1/16W
R40 1-216-837-11 METAL CHIP 22K 5% 1/16W
R41 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R42 1-216-841-11 METAL CHIP 47K 5% 1/16W
R43 1-216-857-11 METAL CHIP 1M 5% 1/16W
R44 1-216-833-11 METAL CHIP 10K 5% 1/16W
R45 1-216-821-11 METAL CHIP 1K 5% 1/16W
R47 1-216-821-11 METAL CHIP 1K 5% 1/16W
R48 1-216-857-11 METAL CHIP 1M 5% 1/16W
R50 1-216-864-11 METAL CHIP 0 5% 1/16W
R51 1-216-833-11 METAL CHIP 10K 5% 1/16W
R52 1-216-846-11 METAL CHIP 120K 5% 1/16W
R53 1-216-819-11 METAL CHIP 680 5% 1/16W
R54 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R55 1-216-845-11 METAL CHIP 100K 5% 1/16W
R56 1-216-833-11 METAL CHIP 10K 5% 1/16W
R57 1-218-880-11 METAL GLAZE 24K 0.50% 1/16W
(E13, E33, E92, AUS, CN/T401:US, CND/T405:US, CND, JEW)
R58 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP, IT, UK/T101:EA)
R60 1-216-809-11 METAL CHIP 100 5% 1/16W
R61 1-216-835-11 METAL CHIP 15K 5% 1/16W
R62 1-216-833-11 METAL CHIP 10K 5% 1/16W
R63 1-216-821-91 METAL CHIP 1K (1608) 5% 1/16W
R64 1-216-821-91 METAL CHIP 1K (1608) 5% 1/16W
R65 1-216-821-91 METAL CHIP 1K (1608) 5% 1/16W
R66 1-216-821-91 METAL CHIP 1K (1608) 5% 1/16W
R67 1-216-837-11 METAL CHIP 22K 5% 1/16W
R68 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R69 1-216-809-11 METAL CHIP 100 5% 1/16W
R70 1-216-809-11 METAL CHIP 100 5% 1/16W
R71 1-216-837-11 METAL CHIP 22K 5% 1/16W
R72 1-216-821-11 METAL CHIP 1K 5% 1/16W
R73 1-216-833-11 METAL CHIP 10K 5% 1/16W
R74 1-216-821-91 METAL CHIP 1K (1608) 5% 1/16W
R80 1-216-821-11 METAL CHIP 1K 5% 1/16W
R81 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R82 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R83 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R84 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R85 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R86 1-216-833-11 METAL CHIP 10K 5% 1/16W
R87 1-216-821-91 METAL CHIP 1K (1608) 5% 1/16W
R90 1-216-841-11 METAL CHIP 47K 5% 1/16W
R91 1-216-841-11 METAL CHIP 47K 5% 1/16W
R92 1-216-845-11 METAL CHIP 100K 5% 1/16W
R93 1-216-845-11 METAL CHIP 100K 5% 1/16W
R94 1-216-847-11 METAL CHIP 150K 5% 1/16W
R95 1-216-833-11 METAL CHIP 10K 5% 1/16W
R96 1-216-845-11 METAL CHIP 100K 5% 1/16W
R97 1-216-845-11 METAL CHIP 100K 5% 1/16W
R98 1-216-847-11 METAL CHIP 150K 5% 1/16W
R99 1-216-833-11 METAL CHIP 10K 5% 1/16W
R100 1-216-833-11 METAL CHIP 10K 5% 1/16W
R101 1-216-833-11 METAL CHIP 10K 5% 1/16W
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-845-11 METAL CHIP 100K 5% 1/16W
R112 1-216-821-11 METAL CHIP 1K 5% 1/16W
R113 1-216-833-11 METAL CHIP 10K 5% 1/16W
R114 1-216-849-11 METAL CHIP 220K 5% 1/16W
R115 1-218-880-11 METAL GLAZE 24K 0.50% 1/16W
< VARIABLE RESISTOR >
RV1 1-223-578-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S1 1-771-053-21 SWITCH, KEY BOARD (TUNE+)
S2 1-771-053-21 SWITCH, KEY BOARD (BAND)
S3 1-771-053-21 SWITCH, KEY BOARD (2)
S4 1-771-053-21 SWITCH, KEY BOARD (4)
S5 1-771-053-21 SWITCH, KEY BOARD (TUNE-)
S6 1-771-053-21 SWITCH, KEY BOARD (1)
S7 1-771-053-21 SWITCH, KEY BOARD (3)
S8 1-771-053-21 SWITCH, KEY BOARD (5)
S10 1-572-922-11 SWITCH, SLIDE (FUNCTION)
S11 1-572-922-11 SWITCH, SLIDE
(E13, E33, E92, AUS, CN/T401:US, CND/T405:US, CND, JEW)
TUNER
