Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 54 —
S12 1-692-605-11 SWITCH, SLIDE (MEGABASS)
S21 1-771-053-21 SWITCH, KEY BOARD (PLAY/PAUSE)
S22 1-771-053-21 SWITCH, KEY BOARD (FR)
S23 1-771-053-21 SWITCH, KEY BOARD (FF)
S24 1-771-053-21 SWITCH, KEY BOARD (STOP)
S25 1-771-053-21 SWITCH, KEY BOARD (PLAYMODE)
S26 1-771-053-21 SWITCH, KEY BOARD (REPEAT/ENT)
S28 1-771-053-21 SWITCH, KEY BOARD (ESP)
< TRANSFORMER >
T1 1-416-184-11 COIL,FM IFT
T2 1-411-603-11 COIL (AM-MIX)
T3 1-431-243-11 TRANSFORMER, DC-DC CONVERTER
T4 1-406-404-11 COIL (MW OSCILATION)
< VIBRATOR >
X1 1-760-423-11 VIBRATOR, CRYSTAL 75kHz
X2 1-579-063-21 VIBRATOR, CERAMIC 4.19MHz
************************************************************
MISCELLANEOUS
*************
4 1-665-407-11 PC BOARD, FLEXIBLE
18 1-571-099-21 SWITCH (1 KEY)
104 1-690-530-21 LEAD (WITH CONNECTOR)
109 1-660-965-11 PC BOARD, SLIDE FLEXIBLE
L7 1-416-164-11 COIL, FERRITE ROD ANTENNA
M901 A-3304-989-A MOTOR ASSY, TURN TABLE
M902 A-3303-403-A MOTOR ASSY, SLED
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
! 1-467-007-21 ADAPTOR, AC (AC-E455) (AUS)
! 1-467-009-11 ADAPTOR, AC (AC-E455)
(E92/T401, T405:US, CND)
! 1-467-012-11 ADAPTOR, AC (AC-E455) (T101:EA)
! 1-467-550-11 ADAPTOR, AC (AC-E455A) (E33/T405:JEW)
! 1-473-115-11 ADAPTOR, AC (AC-E455D) (UK/T405:IT)
! 1-473-116-31 ADAPTOR, AC (AC-E455D) (AEP, IT, E13, CN)
1-528-444-11 BATTERY PACK (BP-DM10)
(T405:CND, E13, E33, E92, AUS, CN)
1-528-444-31 BATTERY PACK (BP-DM10) (T405:US)
1-528-444-81 BATTERY PACK (BP-DM10)
(T405:AEP, IT, UK, JEW)
1-559-906-32 CORD, CONNECTION
(CND,E13,E33,E92,AUS,CN/T401,T405:US)
1-569-007-11 ADAPTOR, CONVERSION 2P (E33/T405:JEW)
1-569-008-11 ADAPTOR, CONVERSION 2P (E13/T101:EA)
1-569-008-21 ADAPTOR, CONVERSION 2P (E13,CN/T101:EA)
1-751-419-11 CORD, CONNECTION
(CND, E13, E33, E92, AUS, CN/T401,T405:US)
1-759-042-21 BATTERY CASE (T405:EXCEPT US, CND)
1-769-723-11 CORD, CONNECTION
(E1CND,3,E33,E92,AUS,CN/T401,T405:US)
3-860-092-11 MANUAL, INSTRUCTION (T101:AEP)(SPANISH)
3-860-092-21 MANUAL, INSTRUCTION
(T101:AEP,UK,EA) (ENGLISH)
3-860-092-31 MANUAL, INSTRUCTION (T101:AEP) (FRENCH)
3-860-092-41 MANUAL, INSTRUCTION (T101:AEP) (DUTCH)
3-860-092-51 MANUAL, INSTRUCTION (T101:AEP)
(SWEDISH)
3-860-092-61 MANUAL, INSTRUCTION (T101:AEP)
(PORTUGUESE)
3-860-092-71 MANUAL, INSTRUCTION (T101:AEP)(GERMAN)
3-860-092-81 MANUAL, INSTRUCTION (T101:AEP, IT)
(ITALIAN)
3-860-093-11 MANUAL, INSTRUCTION (T101:E13, CN)
(CHINESE)
3-860-093-21 MANUAL, INSTRUCTION (T101:E13, CN)
(ENGLISH)
3-860-094-11 MANUAL, INSTRUCTION (T401:AEP)(SPANISH)
3-860-094-21 MANUAL, INSTRUCTION (T401:AEP,UK)
(ENGLISH)
3-860-094-31 MANUAL, INSTRUCTION (T401:AEP) (FRENCH)
3-860-094-41 MANUAL, INSTRUCTION (T401:AEP) (DUTCH)
3-860-094-51 MANUAL, INSTRUCTION (T401:AEP)
(SWEDISH)
3-860-094-61 MANUAL, INSTRUCTION (T401:AEP)
(PORTUGUESE)
3-860-094-71 MANUAL, INSTRUCTION (T401:AEP)(GERMAN)
3-860-094-81 MANUAL, INSTRUCTION (T401:AEP,IT)
(ITALIAN)
3-860-095-11 MANUAL, INSTRUCTION (T401:E13,CN)
(CHINISE)
3-860-095-21 MANUAL, INSTRUCTION (T401:E13,CN)
(ENGLISH)
3-860-096-01 MANUAL, INSTRUCTION (T405:JEW)
(JAPANESE) (ENGLISH)
3-860-096-11 MANUAL, INSTRUCTION (T405:E33,E92,JEW)
(SPANISH)
3-860-096-21 MANUAL, INSTRUCTION
(T405:US, CND, E33, E92, AUS, JEW) (ENGLISH)
3-860-096-31 MANUAL, INSTRUCTION (T405:CND, JEW)
(FRENCH)
3-860-096-41 MANUAL, INSTRUCTION (T405:JEW)
(CHINESE)
3-860-096-51 MANUAL, INSTRUCTION (T405:JEW)
(KOREAN)
3-860-097-11 MANUAL, INSTRUCTION (T405:E13,CN)
(CHINESE)
3-860-097-21 MANUAL, INSTRUCTION (T405:E13,CN)
(ENGLISH)
3-860-100-11 MANUAL, INSTRUCTION (T405:AEP)
(SPANISH)
3-860-100-21 MANUAL, INSTRUCTION (T405:AEP, IT, UK)
(ENGLISH)
3-860-100-31 MANUAL, INSTRUCTION (T405:AEP) (FRENCH)
3-860-100-41 MANUAL, INSTRUCTION (T405:AEP) (DUTCH)
3-860-100-51 MANUAL, INSTRUCTION (T405:AEP)
(SWEDISH)
3-860-100-61 MANUAL, INSTRUCTION (T405:AEP)
(PORTUGUESE)
3-860-100-71 MANUAL, INSTRUCTION (T405:AEP)(GERMAN)
3-860-100-81 MANUAL, INSTRUCTION (T405:AEP, IT)
(ITALIAN)
3-860-101-11 MANUAL, INSTRUCTION (T401:E33, E92)
(SPANISH)
3-860-101-21 MANUAL, INSTRUCTION
(T401:US, CND, E33, E92, AUS) (ENGLISH)
3-860-101-31 MANUAL, INSTRUCTION (T401:CND) (FRENCH)
3-860-113-11 MANUAL, INSTRUCTION (T101:E33, E92)
TUNER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
