D-T101/T401/T405
— 6 — — 7 —
PRINTED WIRING BOARD — TUNER SECTION —
DIAGRAMS
— 8 —
Note on Printed wiring Board:
• X : parts extracted from the component side.
•
r
: Through hole.
• b : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
• Abbreviation
E13 : 220-230V (No charger switch) area
E33 : 100-240V (Without VS) area
E92 : 120V area
AUS : Australian
CND : Canadian
CN : Chinese
EA : Saudi Arabia
FR : French
HK : Hong Kong
IT : Itarian
JEW : Tourist
Caution:
Pattern face side: Parts on the pattern face side seen from
(Conductor Side) the pattern face are indicated.
Parts face side: Parts on the parts face side seen from
(Component Side) the parts face are indicated.
12
A
B
C
D
E
F
G
H
I
J
3456789101112131415161718
To Next Page
