32
Specifications
System
Compact disc digital audio/video system
Laser diode properties
Material: GaAlAs
Wavelength: λ = 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance
of 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture.)
Error correction
Sony Super Strategy Cross Interleave Reed
Solomon Code
D-A conversion
1-bit quartz time-axis control
Channel number
2 channels
Frequency response
20 - 20 000 Hz
+1
–2
dB (measured by JEITA CP-
307)
Output (at 4.5 V input level)
Audio output
Output level 0.7 V rms at 47 kΩ
Recommended load impedance over 10 kΩ
Video output
Output level 1Vp-p at 75 Ω
Recommended load impedance 75 Ω
Headphones (stereo minijack)
Approx. 5 mW + Approx. 5 mW at 16 Ω
Power requirements
For the area code of the model you purchased,
check the upper left side of the bar code on the
package.
• Two LR6 (size AA) batteries: 3 V DC
• AC power adaptor (DC IN 4.5 V jack):
220 V, 50/60 Hz (HK2)
220 V - 230 V, 50/60 Hz (E13/EA5)
220V, 50 Hz (CN2)
Battery life* (approx. hours)
(When you use the player on a flat and stable
surface.)
Playing time varies depending on how the player is
used.
VIDEO CD Audio CD
ESP ON ESP OFF
Two Sony alkaline 2 30 24
batteries LR6SG
* Measured value by the standard of JEITA (Japan
Electronics and Information Technology
Industries Association).
Operating temperature
5°C - 35°C (41°F - 95°F)
Dimensions (w/h/d) (excluding
projecting parts and controls)
Approx. 152.4 × 25.4 × 152.4 mm
Mass (excluding accessories)
Approx. 226 g
Design and specifications are subject to change
without notice.
