Sony DADC - Page 27

25
13,5
7 16,5
23
6,5
6,5
137,5
R 3
6,5
6,5
6
5
11,5
34
76
186
12,5
top
oben
grain direction
no spine text here (not legible, locking area)
outside
Außenseite
Explanation:
Final dimension
Bleed
Minimum of blank film dimension
must have at least 20 mm distance
to final dimension
All dimensions in mm
Film Specifications: Inlay Card for Super Jewel Box
Film Specifications: Inlay Card for Super Jewel Box
199
150,5
3
3
3
