Specifications for Printwork
Super Jewel Box Inlay
13,5
7 16,5
23
6,5
+/-0,2
6,5
+/-0,2
137,5
+/-0,2
R 3
6,5
+/-0,2
6,5
+/-0,2
6
5
11,5
34
76
186
+/-0,2
12,5
top
grain direction
no spine text here (not legible, locking area)
outside
All dimensions in mm
P
aper:
● chlorine-free
● wood-free
● glossy double-coated on both sides
● white art paper
Cover page:
● 160 g/m
2
- 180 g/m
2
Condition at time of supply: upright in carton box (see fig. page 43)
Note: With inlay cards printed on both sides, the externally visible side has to be defined (please mark on
the films outside of the area to be printed).
