Sony DAV-C770 - Rear Panel; Rear Panel Connectors

13
GB
1 SPEAKER jacks (19)
2 AM antenna (21)
3 VIDEO 1 jacks (23)
4 VIDEO 2 jacks (23)
5 COMPONENT VIDEO OUT/SCAN
SELECT switch (75)
6 MONITOR OUT (VIDEO/S VIDEO)
jacks (24)
7 VIDEO 2 (OPTICAL DIGITAL IN)
jack (24)
8 COMPONENT VIDEO OUT jacks (23)
9 FM 75Ω COAXIAL antenna jack (21)
Rear Panel
WOOFER 3Ω
IMPEDANCE
USE
EXCEPT
WOOFER 3Ω
VIDEO 1
COMPONENT VIDEO OUT
VIDEO 2
VIDEO 2
MONITOR
OUT
FRONT
R
FRONT
L
REAR
R
REAR
L
CENTER WOOFER
COAXIAL
AUDIO OUT
AUDIO IN
LR
LR
LR
VIDEO OUT
VIDEO IN
VIDEO INAUDIO IN
YP B /C B P R /C R
AM
FM
75Ω
OPTICAL
DIGITAL
IN
S VIDEOVIDEO
DVD
ONLY
SPEAKER
INTERLACE
SELECTABLE
SCAN SELECT
COMPONENT
VIDEO OUT
continued
