Getting Started – BASIC –
The following is the connection of the unit to the speakers and TV.
Refer to the connection diagram below, and read the additional information from 1 to 4 on the
following pages.
Step 1: Connecting the System and TV
SPEAKER
ANTENNA
FRONT R FRONT L SUR R SUR L CENTER WOOFER
EURO AV
OUTPUT(TO TV)
COAXIAL
AM
FM75
AM loop antenna (aerial)
Subwoofer
AC power cord (mains lead)
FM wire antenna
(aerial)
TV
Front speaker (R)
Center speaker
Front speaker (L)
Surround speaker (R)
Surround speaker (L)
:Signal flow
cont
nue
To Next Page
