Ref. No. Part No. Description Ref. No. Part No. Description
DCR-DVD306E/DVD308/DVD308E/DVD708/DVD708E_L2
A-1228-523-A MS-346 BOARD, COMPLETE
***********************
< CONNECTOR >
CN7401 1-819-611-21 MEMORY STICK DUO CONNECTOR 10P
CN7402 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
< FERRITE BEAD >
FB7401 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB7402 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB7403 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
FB7404 1-469-580-11 INDUCTOR, FERRITE BEAD (1005)
< RESISTOR >
R7404 1-218-942-11 RES-CHIP 120 5% 1/16W
R7405 1-218-942-11 RES-CHIP 120 5% 1/16W
R7406 1-218-942-11 RES-CHIP 120 5% 1/16W
R7407 1-218-942-11 RES-CHIP 120 5% 1/16W
A-1228-517-A OC-002 BOARD, COMPLETE
***********************
< SWITCH >
* S7601 1-786-545-41 SWITCH, PUSH LEVER (S)
(PANEL OPEN/CLOSE)
A-1228-513-A PD-315 BOARD, COMPLETE
***********************
< CAPACITOR >
C6302 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6303 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6304 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6305 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6306 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN6301 1-818-072-51 CONNECTOR, FFC/FPC (ZIF) 30P
CN6302 1-573-915-51 CONNECTOR, FFC/FPC (ZIF) 6P
* CN6304 1-818-069-51 CONNECTOR, FFC/FPC (ZIF) 6P
CN6305 1-818-071-51 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D6302 6-500-941-01 DIODE MAZS056008S0
* D6303 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D6304 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D6305 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
< TRANSISTOR >
Q6301 8-729-427-67 TRANSISTOR XP421F-TXE
Q6302 8-729-427-37 TRANSISTOR XP411F-TXE
Q6303 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
< RESISTOR >
R6301 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R6302 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R6303 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R6307 1-218-978-11 RES-CHIP 120K 5% 1/16W
R6309 1-218-989-11 RES-CHIP 1M 5% 1/16W
< VARISTOR >
* VD6302 1-802-279-11 VARISTOR (SMD)
A-1228-515-A RV-002 BOARD, COMPLETE
***********************
< SWITCH >
S7502 1-786-180-31 SWITCH, PUSH (1 KEY) (PANEL REVERSE)
Electrical parts list of the VC-484 board is
not shown.
Pages 5-12 to 5-18 are not shown.
MS-346 OC-002 PD-315 RV-002
