Sony DCR-DVD708E - Mounted Parts Location

4-41
4-3. PRINTED WIRING BOARDS
DCR-DVD306E/DVD308/DVD308E/DVD708/DVD708E_L2
CD-687
no mark : side A
*
mark : side B
4-4. MOUNTED PARTS LOCATION
C7002 B-1
C7003 B-2
C7005 B-2
C7007 A-2
C7011 A-2
C7015 A-2
C7016 A-1
C7017 A-2
C7018 A-2
C7023 B-1
C7024 B-1
C7025 A-1
C7026 A-1
C7027 A-1
C7028 B-1
C7029 A-1
CN7001 B-1
FB7001 A-2
* IC7002 B-2
IC7003 B-1
L7001 B-2
L7002 B-1
Q7001 A-1
Q7002 B-2
R7002 B-2
R7004 B-2
R7005 B-2
R7006 B-2
R7013 B-1
R7014 B-1
R7015 B-1
R7016 B-1
RB7001 A-2
SE7001 A-2
SE7002 A-1
CD-687 BOARD
