5-2. ELECTRICAL PARTS LIST
DCR-DVD306E/DVD308/DVD308E/DVD708/DVD708E_L2
BL-007 CD-687
A-1228-519-A BL-007 BOARD, COMPLETE
***********************
< CAPACITOR >
C5901 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5902 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN5901 1-818-046-51 CONNECTOR, FFC/FPC 20P
* CN5902 1-817-560-71 CONNECTOR, FPC (ZIP) 21P
< DIODE >
* D5901 6-501-591-01 DIODE NESW007AT-T099 (BACKLIGHT)
D5902 6-500-941-01 DIODE MAZS056008S0
A-1228-527-A CD-687 BOARD, COMPLETE
***********************
(IC7002 is not supplied, but this is included in CCD block assy.)
< CAPACITOR >
C7002 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C7003 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C7005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7007 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V
C7011 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C7015 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7017 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7018 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7023 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C7024 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7025 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7026 1-100-251-11 CERAMIC CHIP 0.047uF 10% 10V
C7027 1-100-251-11 CERAMIC CHIP 0.047uF 10% 10V
C7028 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7029 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
CN7001 1-820-586-51 CONNECTOR, FFC/FPC 28P
< FERRITE BEAD >
FB7001 1-400-331-11 FERRITE, EMI (SMD) (1005)
< IC >
IC7002 A-1236-643-A CCD BLOCK ASSY (CCD IMAGER) (Note)
IC7003 8-759-489-19 IC uPC6756GR-8JG-E2
< COIL >
L7001 1-400-588-11 INDUCTOR 10uH
L7002 1-400-588-11 INDUCTOR 10uH
< TRANSISTOR >
Q7001 6-550-234-01 TRANSISTOR UNR32A300LS0
Q7002 8-729-055-21 TRANSISTOR 2SC5096-O/R (TE85L)
< RESISTOR >
R7002 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R7004 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7005 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7006 1-218-966-11 RES-CHIP 12K 5% 1/16W
R7013 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7014 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7015 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7016 1-218-965-11 RES-CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB7001 1-234-379-21 RES, NETWORK 22K (1005X4)
< SENSOR >
SE7001 1-479-022-61 SENSOR, ANGULAR VELOCITY (32.2kHz)
(YAW)
SE7002 1-479-022-51 SENSOR, ANGULAR VELOCITY (30.8kHz)
(PITCH)
Note: イメージャの交換時は4-4ページのイメージャ交
換時の注意を必ずお読みください。
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-3 when changing the imager.
