Sony DCR-HC28E - Mounted Parts Location

4-36E
DCR-HC28E_L2
no mark : side A
*
mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
PD-281, SI-051
PD-281 BOARD SI-051 BOARD
4-4. MOUNTED PARTS LOCATION
C9603 A4
C9605 B4
C9606 B4
CN9601 A2
CN9603 B2
CN9604 A4
CN9605 B5
D9602 B4
* D9603 B5
* D9604 C5
* D9605 A5
Q9601 A4
Q9602 A4
R9602 A3
R9603 A3
R9604 A3
R9607 B4
* C616 D1
* C617 D1
CN601 C1
* CN602 D2
CN604 B1
* CN605 D2
* D602 D1
* D603 C1
D606 A1
F601 B1
F602 B1
FB601 D1
FB602 D1
* LF602 C1
* LF603 C1
* R623 B1
* R624 B1
