Sony DCR-HC28E - Electrical Parts List

5-12
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DCR-HC28E_L2
CD-631 FP-031 FP-032 FP-228 FP-380 FP-381 FP-386 LB-121
A-1204-536-A CD-631 BOARD, COMPLETE
**********************
(IC101 is not included in CD-631 complete board.)
< CAPACITOR >
C101 1-124-779-00 ELECT CHIP 10uF 20% 16V
C102 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C104 1-124-779-00 ELECT CHIP 10uF 20% 16V
< CONNECTOR >
CN101 1-766-344-51 CONNECTOR, FFC/FPC 14P
< IC >
IC101 8-753-244-71 ICX611NKF-13 (CCD IMAGER)
< COIL >
L101 1-400-588-11 INDUCTOR 10uH
< TRANSISTOR >
Q101 8-729-423-55 TRANSISTOR 2SC3931-D
< RESISTOR >
R101 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
(Not supplied) FP-031 FLEXIBLE BOARD
********************
(This flexible board is included in MD (N100) SUB ASSY A (A-1080-997-A).)
< DIODE >
D901 6-500-652-01 DIODE GL453SE0000F (TAPE LED)
< HOLE ELEMENT >
H901 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (S REEL)
H902 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (T REEL)
< CONNECTOR >
MIC902 1-818-576-11 PIN, CONNECTOR (WITH DETECTION SWITCH)
< TRANSISTOR >
Q901 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE END)
Q902 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE TOP)
< SWITCH >
S901 1-786-448-22 SWITCH, PUSH (1 KEY) (CC DOWN)
(Not supplied) FP-032 FLEXIBLE BOARD
********************
(This flexible board with S903 is included in
MD (N100) SUB ASSY A (A-1080-997-A).)
1-677-049-11 FP-228 FLEXIBLE BOARD (DEW SENSOR)
********************
* 1-867-778-11 FP-380 FLEXIBLE BOARD
********************
1-867-779-13 FP-381 FLEXIBLE BOARD
********************
(BH001 and J001 are not included in FP-381 flexible board.)
< BATTERY TERMINAL >
BH001 1-780-064-21 BATTERY TERMINAL BOARD
< JACK >
J001 1-815-792-11 CONNECTOR, DC-IN (7.2V)
A-1153-842-A FP-386 FLEXIBLE BOARD, COMPLETE
******************************
< SWITCH >
S101 1-786-180-31 SWITCH, PUSH (1KEY) (PANEL REVERSE)
A-1024-537-A LB-121 BOARD, COMPLETE
**********************
< CAPACITOR >
C301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C302 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN301 1-818-046-51 CONNECTOR, FFC/FPC 20P
* CN302 1-817-560-51 CONNECTOR, FPC (ZIP) 21P
< DIODE >
D301 6-500-941-01 DIODE MAZS056008S0
* D302 6-501-325-01 DIODE NESW007T-T017 (BACKLIGHT)
< RESISTOR >
R304 1-218-989-11 RES-CHIP 1M 5% 1/16W
A-1204-539-A PD-281 BOARD, COMPLETE
**********************
< CAPACITOR >
C9603 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C9605 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C9606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN9601 1-817-513-51 CONNECTOR, FFC/FPC (ZIF) 30P
CN9603 1-573-915-51 CONNECTOR, FFC/FPC (ZIF) 6P
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-3 when changing the imager.
PD-281
