5-13
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-HC28E_L2
PD-281 SI-051
CN9604 1-573-915-51 CONNECTOR, FFC/FPC (ZIF) 6P
CN9605 1-815-031-51 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D9602 6-500-941-01 DIODE MAZS056008S0
* D9603 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D9604 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D9605 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
< TRANSISTOR >
Q9601 8-729-427-67 TRANSISTOR XP421F-TXE
Q9602 8-729-427-37 TRANSISTOR XP411F-TXE
< RESISTOR >
R9602 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R9603 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R9604 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R9607 1-218-989-11 RES-CHIP 1M 5% 1/16W
A-1204-538-A SI-051 BOARD, COMPLETE
**********************
< BATTERY >
0* BT601 1-756-640-11 BATTERY, LITHIUM SECONDARY
< CAPACITOR >
C616 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C617 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
< CONNECTOR >
CN601 1-815-794-21 CONNECTOR (MULTIPLE) (A/V OUT)
CN602 1-778-507-21 PIN, CONNECTOR (PC BOARD) 4P
CN604 1-794-276-11 CONNECTOR, SQUARE TYPE 4P
CN605 1-818-074-51 CONNECTOR, FFC/FPC (ZIF) 36P
< DIODE >
D602 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D603 6-500-776-01 DIODE MAZW068H0LS0
D606 6-500-512-01 DIODE CL-330IRS-X-TU
< FUSE >
0 F601 1-576-647-11 FUSE (0.2A/50V)
0 F602 1-576-647-11 FUSE (0.2A/50V)
< FERRITE BEAD >
FB601 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
FB602 1-414-760-21 BEAD, FERRITE (CHIP) (1608)
< LINE FILTER >
LF602 1-400-633-21 COMMON MODE CHOKE COIL
LF603 1-400-633-21 COMMON MODE CHOKE COIL
< RESISTOR >
R623 1-216-801-11 METAL CHIP 22 5% 1/10W
R624 1-216-801-11 METAL CHIP 22 5% 1/10W
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Refer to page 5-1 for mark 0.
Electrical parts list of the VC-416 board is
not shown.
Pages 5-14 to 5-18 are not shown.
To Next Page
