DCR-PC53E/PC55/PC55E
HELP
MS tape
MS dust protection sheet
Control switch block
FP-049 flexible board
Adhesive surface
9 Attach the adhesive surface.
5 FP-053 flexible board
6 FP-053 flexible board assembly
FP-053 flexible board assembly
1 FP-222 flexible
board
4 Flexible guard
N
2
3
LCD hinge assembly
LCD hinge assembly
LCD hinge assembly
8 Wrap around
three times.
FP-053 flexible board assembly
Caution
Caution
FP-053 flexible board
FP-222 flexible board
Silver
Screw
M1.4x2.5
3-389-523-22
N
HELP 04
HELP 06
HELP 05
7
Rotate 90 °
