Sony DCR-PC53E - Page 45

DCR-PC53E/PC55/PC55E
For Printed Wiring Board
• Refer to page 4-55 for common note for printed wiring board.
• : Uses unleaded solder.
4-59 4-60
FP-051/FP-052
>PI<
FP-051
FP-051 BOARD
11
1-864-925-
EASYBATT INFOBACK LIGHT
BACK LIGHT
ON/OFF
2nd
START/STOP
16
R401
R402
R403
S401
S402
S403
S404S405
D401
LND401 LND402 LND403 LND404 LND405 LND406
>PI< FP-052
FP-052 BOARD
11
1-864-926-
MEMORY STICK DUO
CONNECTOR
1
10
12
11
11
1
D001
CN8102
LND001
LND002
LND003
LND004
LND005
LND006
LND007
LND008
LND009
LND010
LND011
LND811
