5-18
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-SR210E/SR220/SR220D/SR220E/
HDR-SR10/SR10D/SR10E_L2
< RESISTOR >
R6101 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R6102 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R6105 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R6111 1-208-649-11 RES-CHIP 39 0.5% 1/16W
R6112 1-218-965-11 RES-CHIP 10K 5% 1/16W
R6115 1-208-931-11 RES-CHIP 68K 0.5% 1/16W
R6119 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R6120 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R6134 1-208-898-11 METAL CHIP 3K 0.5% 1/16W
R6138 1-218-969-11 RES-CHIP 22K 5% 1/16W
R6139 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R6140 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R6141 1-218-981-91 RES-CHIP 220K 5% 1/16W
R6143 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R6144 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R6145 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R6146 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R6148 1-211-969-11 METAL CHIP 10 0.5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB6101 1-234-381-11 RES, NETWORK 100K (1005X4)
RB6102 1-234-381-11 RES, NETWORK 100K (1005X4)
************************************************************
A-1494-352-A ST-189 BOARD, COMPLETE
**********************
< CAPACITOR >
C5052 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5053 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C5054 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C5055 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
0*C5056 1-114-393-11 ELECT 70uF 99% 330V
< CONNECTOR >
* CN5051 1-779-331-51 CONNECTOR, FFC/FPC 14P
* CN5052 1-816-645-51 FFC/FPC CONNECTOR (LIF) 14P
< DIODE >
D5052 6-500-619-01 DIODE RB520S-40TE61
0D5053 6-501-096-01 DIODE CRF02 (TE85R)
< IC >
0IC5051 6-707-554-01 IC TPS65552DGQR
< COIL >
L5051 1-412-027-11 INDUCTOR 2.2uH
< TRANSISTOR >
0*Q5051 6-551-686-01 TRANSISTOR TIG030TS-S-TL-E
< RESISTOR >
R5053 1-208-947-11 METAL CHIP 330K 0.5% 1/16W
R5054 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
• Refer to page 5-1 for mark 0.
R5058 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R5059 1-216-809-11 METAL CHIP 100 5% 1/10W
R5060 1-218-989-11 RES-CHIP 1M 5% 1/16W
< TRANSFORMER >
0 T5051 1-443-568-31 TRANSFORMER, D.C.-D.C.CONVERTER
************************************************************
Electrical parts list of the VC-516 is not
shown.
Pages 5-19 to 5-27 are not shown.
ST-189PD-356
